Nice Electromechanical Barrier Gate Operator for Enterprises and Institutions

Parking Barrier Gate Brief Introduction:

WEJOIN Commercial Servo Barrier Gate WJCB02

The fastest running speed can be 0.6 seconds (model WJCB02E, 0.6~2s adjustable), 100% duty cycle, and free maintenance make the barrier be proper for the toll station and parking system!

Parking Barrier Gate Technical Data:

Parking Barrier Gate Features:

1.DC permanent magnet synchronous motor(PMSM), servo control.

2.Superior performance, equivalent to the main motor of the CNC machine tool and the electric vehicle motor, it has high control precision, high torque density, good torque balance, low power consumption, high efficiency, less heat, and low noise.

3.Bi-direction boom holder design: left-installation and right-installation can be exchanged easily and quickly.

4.Electronic clutch design: more convenient to unlock or lock the motor when power off. (patented technology)

5. Three tension spring crank transmission design, for a more stable and reliable structure. (patented technology)

6.No limit switch design, accurate encoder detection, detecting boom position when power on. And open/close speed is adjustable.

7.More sensitive and reacting faster when reversing upon obstacles.

8.With counting, delay auto-closing, auto-aging test, alarm when lifting boom without permission, motorcade passing function.

9.LCD display controller, more humanized operation and setting.

10.NO/NC wire control signal input is optional.

11.Integrated RS485 communication, RJ45 network, infrared photocell, loop detector interface, radar module, and more secondary development.
