Humanized Clutch Parking Lot Barrier Gate IP54 RS485 Infrared Photocell

Price Negotiable

Price: negotiation

MOQ: 1 unit

Delivery Time: 3-7 working days

Brand: WEJOIN

Product Description

Parking Lot Gate Barrier Automatic Boom Barrier Gate Traffic Barrier

Production Series

Model	Description	Max boom length (L≤meter)	Action time (second)	Boom height (meter)
WJDZ1XX/A	Slow speed, straight	L≤6 m	6	0 .83
WJDZ1XX/B	Medium speed, straight	L≤4 .5 m	3	0 .83
WJDZ1XX/C1	90° Folding boom	L≤5 m	6	0 .83
WJDZ1XX/C2	180° Folding boom	L≤5 m	6	0 .83
WJDZ1XX/D	Quick speed straight boom	L≤3 m	1	0 .83
WJDZ1XX/E1	Fence boom	L≤4 .5 m	6	0 . 9
WJDZ1XX/E2	Fence boom	L≤4 m	6	1 . 5

Notice: The "Boom Height" means height from the boom holding point to the ground

Functions and Features

1) The humanized clutch device: In case of power off, unlock the clutch device and raise the boom manually. By the time the power is supplied, lock the clutch device to make it work normally again.

2) Special spring device: Both the compression spring and tension spring can be used in the machine. Using the compression spring can avoid accidents caused by the tension spring.

3) Three control buttons: for boom raising, falling, and pausing.

4.) Boom backtrack function: the boom will rise if it hits something when falling.

5) Infrared photocell design: for avoiding the crash when the boom falls, so as to prevent the vehicles from being pressed.

6) Both external and internal loop detectors are supported.

7) 'Open','Close'and'Stop' controlling interfaces.

8) RS-485 communication serial interface (optional).

9) Traffic light signal connection device: red light for the stop; green light for the pass.

10) Remote control and wire control for selection.

WEJOIN's Main Advantages

1. The global leading company for barrier gate

2. Master of core technology and innovation

3. The intelligent quality manufacturing process and automatic flexible production

4. The global advanced manufacturing process and testing equipment

5. Servo, variable frequency, double speed,bi-direction motor, and other leading technique

6. High speed and low speed coexist in motor

7. Integral service network covering first-tier and second-tier cities, and more under the construction service network
