304 Stainless Steel Automatic Rotary Powder Filling Machinery Custom Made

Price Negotiable

Price: 1000USD

MOQ: 25

Delivery Time: 25

Brand: GD8-200B

Product Description

304 Stainless Steel Automatic Rotary Powder Filling Machinery Custom Made

Performance

The automatic rotary bagging machine, fast-acting and reliable, is ideal for flexible bag styles and ranges as well as offers quick changeovers. With different metering and filling equipment, it is suitable for a variety of industries and products (Granules, Powder, Liquids and Pastes or other nature).

Features :

SIEMENS PLC & Colorful Touch-Screen controlled fully automatic machine
Frequency Conversion Speed Adjuster and SMC Cylinder Driven
Widely flexible pouch formats and product types
Self-diagnostic function-no filling, no heating, nor sealing if the bags not open or not open completely
Auto-brake for self-protection when machine stops
Customized zipper auto-open construction to avoid pouch broken nor deformed
Applicable bags material-Laminated film, monolayer PE, PP and paper

Technical parameters :

Equipment model	GD8-200B
Equipment material	304 stainless steel
Pneumatic component	SMC,AirTAC
Vacuum component	Vacuum generator (SMC)
Drive mode	Frequency conversion motor drive
Measuring type	Auger filler, linear weigher
Operation interface	Touch screen(double language:Chinese and English)
Bag materials	Heat sealable film as PA/PE,PET/PE,AL film etc.
Bag size	W:70~200mm L:100~300mm (date coding requires≥140mm length)

Filling range	5~1500g
Packing speed	20~45bags/min (depended on the product and filling weight)
Package accuracy	Error≤±1%
Weight	RZ6-200:800kg
	RZ8-200:1000KG
Dimension	RZ6-200:147513251480(L,W,H)
	RZ8-200:163514551480(L,W,H)
Total power	RZ6-200:1.5kw
	RZ8-200:2.3kw
Driving power source	380V Three-phase Five-line 50HZ
Control power source	DC24V
Compress air requirement	≥0.45m³/min (compress air is provided by user)
