5L Pure Water Bottle Filling Machine 3 In 1 Liquid Filler Equipment
5L Pure Water Bottle Filling Machine 3 In 1 Liquid Filler Equipment
Quick Detail:
Machine structure: 3 in 1 filling machine
Filling type: Normal pressure filling
Bottle type: 5L plastic bottle
Filling material: Pure water
Operation manner: Auto / Manual
Description:
The bottle filling machine is monoblock filling machine which integrate washing, filling and capping machine in one unit. It is used to fill pure water, mineral water, and other non-carbonated water into plastics bottles. The bottles can be various, but the bottle mouth must be the same so that they can be used in one machine.
Specifications:
| Model | CGF8-8-3 | CGF12-12-4 | CGF18-18-6 | CGF24-24-8 | CGF32-32-10 |
| Washing Head No | 8 | 12 | 18 | 24 | 32 |
| Filling Head No | 8 | 12 | 18 | 24 | 32 |
| Capping Head No | 3 | 4 | 6 | 8 | 10 |
|
Rated Capacity (500ml) |
3000BPH | 4000BPH | 5000-7000BPH | 8000-12000BPH | 12000-15000BPH |
| Overall Size |
1900*1420* 2000mm |
2200*1600* 2300mm |
2450*1900* 2300mm |
2750*1180* 2400mm |
4000*2300* 2300mm |
| Weight | 1.5T | 2.2T | 3.0T | 4.0T | 8.0T |
|
Power (KW) |
3.0kw | 3.5kw | 4.0kw | 4.8kw | 7.6kw |
| Rated Voltage | Customized | Customized | Customized | Customized | Customized |
Competitive Advantage:
1. One year warranty for the whole system
2. Free equipment installation and debugging
3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price
4. Every 3 years, we can help to overhaul the machine free (Labor)
5. We can provide internship service and help you train the operator and mechanic
6. Free production technology and process configuration
7. We can help you to design the production line, workshop and provide turn-key project
Market Distribution:
| Market | Revenue(Previous Year) | Total Revenue (%) |
| Africa | confidential | 40% |
| Middle east | confidential | 15% |
| America | confidential | 5% |
| Euro | confidential | 4% |
| Middle Aisa | confidential | 3% |
| South-east Asia | confidential | 3% |
| Domestic | confidential | 30% |
please kindly click the play button to watch the video
