500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Production Equipment / Plant / Machine / System / Line
Price:
20000-40000USD
MOQ:
1 set
Delivery Time:
30 Working Days After Deposit
Brand:
FillPack
Product Description
Decription of CGF50-50-12 Pure drinking water PET bottle 3 in 1 bottling line for 0-2L bottle
>>>Characteristics:
★The 500ml water production machine is used in production of non-soda drink of mineral-pure water packed in polyester bottles. Washing, filling and capping are integrated in one machine.
★The whole machine is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.
★The 500ml water production machine is used in production of non-soda drink of mineral-pure water packed in polyester bottles. Washing, filling and capping are integrated in one machine.
★The whole machine is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.
★1.Except the down framework, the transmission parts and some parts that must be made of special materials. Other spare parts are made of stainless steel 304.
★2.By adjusting the height of the rotary parts to adapt for different bottle height.
★2.By adjusting the height of the rotary parts to adapt for different bottle height.
★1) Adopted Germanyanti-corrosion non-maintaining bearing that can reduce the pollution of filling to the environment.
★2) This filling system has an automatic temperature control system.
★2) This filling system has an automatic temperature control system.
This 500ml water production machine is the highest degree of accuracy of 3 in 1 machine, it is important for the machine to run stably and the product quality.
A group of photoelectric switches are settled on cap-falling guide. The machine will stop when there is no cap on the guide.
A group of photoelectric switches are settled on cap-falling guide. The machine will stop when there is no cap on the guide.
Parameters | |
Model | CGF50-50-12 |
Capacity(B/H) | 24000 |
Bottle size | Neck :φ50-100mm:Height:150-320mm |
Water pressure | 0.18-0.25Mpa |
Water consumption(kg/h) | 1000 |
Washing station | 18 |
Loading-Dripping-discharge station | 2-2-2 |
Filling precision | <+1MM |
Air pressure | 0.5Mpa |
Air consumption (m³/min) | 0.3 |
Power(kw) | 8 |
Weight(kg) | 4000 |
Dimension(L*W*H)(mm) | 4550*3500*2400 mm |
Electrical apparatus | ||
Transducer | Simens-Germany | |
Touch screen | Simens-Germany | |
PLC | Simens-Germany | |
Stabilized voltage supply | MingWei-TaiWan | |
Contactor | Schnider-French | |
Approach switch | Schnider-French | |
Air switch | Schnider-French | |
We have 3-in-1 washing-filling-capping machine for 0-2L bottle and 3-10L bottle.
We also have linear type washing-filling-capping machine for 0-2L bottle and 3-10L bottle.
The capacity of linear type is not faster than 3-in-1, and it's floor area is slightly larger, but the price is more cheaper than 3-in-1.
Our Washing-filling-capping machines (3-in-1 and Linear type) | ||||||
3in1(0-2L bottle) | Capacity(bottle per hour) | 3in1(3-10L bottle) | Capacity | Linear type | Capacity | |
CGF8-8-3 | 2000-3000BPH | CGF8-8-3B | 0-1000 | CGF4-4-1 | 500BPH | |
CGF12-12-4 | 3000-4000BPH | CGF12-12-4B | 0-1500 | CGF6-6-1 | 750BPH | |
CGF18-18-6 | 6000-7000BPH | CGF18-18-6B | 0-2500 | CGF8-8-1 | 1000BPH | |
CGF24-24-8 | 11000-12000BPH | CGF24-24-8B | 0-3500 | CGF10-10-1 | 1500BPH | |
CGF32-32-10 | 14000-15000BPH | CGF32-32-10B | 0-5000 | CGF12-12-1 | 2000BPH | |
CGF40-40-10 | 19000-20000BPH | |||||
CGF50-50-12 | 23000-24000BPH | |||||
More capacities if you need, we can also customize that for you. please check them on our website or contact the sales consultant directly. Please find the contact information at contact us. | ||||||
