1000mg Output Ozone Generator Accessories Air Cooling Ceramic Tube
Ozone generator accessories 1000mg Output Air Cooling Ceramic Ozone Tube
Ozone generator accessories 1000mg Output Air Cooling Ceramic Ozone Tube
Features:
- Stable ozone output.
Air cooled for internal & external electrodes with low temperature rise of continuously working, high efficiency and stable ozone output.
- Low working voltage
The working voltage is only 10% of the similar products, stable capacity but with low ozone dissipated.
- Small in size.
It saves space effectively. The size is 1/4 smaller than similar products.
- Easy to maintain and install
Ozone output: 3g/h, 5g/h, 6g/h, 7g/h
| Item | Unit | 500MG | CH-PTF1G | ||
| / | / | 500 mg/h | 1G(12V) | 1G (220V) | 1G(110V) |
| Ozone tube type | / | Quartz tube | Ceramic tube | ||
| Ambient temperature | ℃ | 0-30 | 21.6 | 25 | 23.6 |
| Ambient humidity | % | ≤80%Rh | 40 | 50 | 21.6 |
| Power | W | ≤8 | ≤14.4 | ≤15 | ≤15 |
| Ozone output | G/Hr | 500 | 0.88~1.2 | 0.88~1.8 | |
| Line power supply | V/Hz | DC12/220V | DC12 | AC110/60 220/50 | |
| Cooling way | / | Air cooling | |||
| Power supply dimensions | mm | 79*29.5*24.5 | 105*57*50 | 96*47*32 | 96*47*32 |
| ozone tube dimensions | mm | 66.6*28*15 | 125*50*50 | ||
| Ozone tube weight | Kg | 0.03 | 0.2 | ||
| Power supply weight | Kg | 0.09 | 0.15 | ||
Ozone generator accessories 1000mg Output Air Cooling Ceramic Ozone Tube
Ozone generator accessories 1000mg Output Air Cooling Ceramic Ozone Tube
