O2 Concentrator Two Towers Oxygen Molecular Sieve Cylinder For Ozone Equipment
o2 concentrator Two towers oxygen molecular sieve cylinder for ozone equipment
o2 concentrator Two towers oxygen molecular sieve cylinder for ozone equipment
Composition material:
• It is composed of oxygen adsorption tower, gas collecting tank, solenoid valve, electric control board, oxygen outlet pressure regulating valve, flow restrictor, etc.
• Using high-quality molecular sieve as raw material, stable and reliable work.
• This parts is manufactured according to the standard of medical oxygen generator, with high oxygen concentration.
The main function:
• Used for oxygen supply and oxygen inhalation in homes, hospitals, clinics, and nursing centers.
• As the oxygen source of the ozone generator.
Specification
| Product name | Two towers oxygen molecular sieve cylinder |
| Model No. | HY-10L-G |
| Oxygen concentration | 90%±3% |
| Oxygen flow rate | ≥10L/min |
| Gas Input | ≥140L/min@0.22MPa |
| Gas dew point requirements | ≤-50℃ |
| Input voltage | AC100-240V/50-60Hz |
| Power consumption | ≤20W |
| Oxygen pressure | 40KPa |
| Ambient temperature | 5-45℃ |
| Environment humidity | ≤80%RH |
| Dimension | 616x185x180mm |
| Net weight | 11kg |
Notice:
* Do not turn the pressure regulating valve; the pressure regulating valve requires professionals to connect the pressure gauge according to the design standard, and adjust it by reading the value of the instrument online. The pressure valve needs to be locked after the adjustment.
* If multiple two tower oxygen molecular sieve cylinder are required to synthesize an oxygen generator to use, it needs to be customized in advance.
o2 concentrator Two towers oxygen molecular sieve cylinder for ozone equipment
