5g/hr Ceramic Ozone Tube 12V 24V 110V 220V Ozone Generator Parts Small In Size

Price Negotiable

Price: USD 20-60/set

MOQ: 1 set

Delivery Time: Negotiable

Brand: Netech

Product Description

5g/hr Ceramic Tube 12V 24V 110V 220V Ozone Generator Parts Made In China

Features:

1. Extremely low rate of ozone decay & high ozone concentration.

2. Domestic product-got domestic in 2008.

3. Air cooled for internal & external electrodes with low temperature rise of continuously working, high efficiency and stable ozone output.

4. Low working voltage

5. Small in size.

6. Easy to maintain and install

Material:

Imported material of high pure ceramic, SS 316L of internal electrode, connections which are best anti-oxidation material for ensuring several years running.

Application:

Many schools are already using Ozone generators because it is safe to use, economical to operate, requires no chemical consumables, and involves minimal maintenance.

Ozone Benefits:

Surface cleanion

Air purification

Safe to Use

Improved Air Quality

Eliminates all kinds of odor

Specification:

Item	Unit	CH-PTF
		3GA-1 (12V,24V)	3GA-1 (220V)	3GA-1 (110V)	5GA-1 (12V,24V)	5GA-1 (220V)	5GA-1 (110V)
Ambient temperature	℃	21			21
Ambient humidity	%	40			40
Power	W(±10%)	50			55
Working frequency	KHz (±10%)	15.9			16
Working voltage	KV(±10%)	2.8			3
Oxygen feed flow rate	LPM	0.5-1			0.5-2.5
Ozone concentration	Mg/L	70-49			72-34
Ozone output	G/Hr	2.1-2.9			2.2-5.1
Ozone output adjustable range	%	20~100			20~100
Line power supply	V/Hz	12V 24V 110/60 220/50
Cooling way	/	Air cooling
Cooling fan	/	150
Diameter of cooling fan	mm	120			120
Diameter of gas inlet/outlet	mm	EDФ6
Power supply dimensions	mm	1587568			1587568
ozone tube dimensions	mm	1659593			1859593
Ozone tube weight	Kg	0.55			0.66
Power supply weight	Kg	0.6			0.6
