150w Industrial UFO High Bay Lights Coated IK08 For Ceiling Wall
150w Industrial UFO High Bay Lights Black Coated IK08 For Ceiling Wall led high bay light fixtures
Product Description:
| Item No. | YAHB-05-100 | YAHB-05-150 | YAHB-05-200 |
| Wattage | 100W | 150W | 200W |
| Voltage | 100-277V | 100-277V | 100-277V |
| Dimension | L282*H115mm | L342*H119mm | L403*H128mm |
| Luminous efficacy | >130lm/w | >130lm/w | >130lm/w |
| LED Qty | 144PCS | 210PCS | 288PCS |
| LED Type | SMD3030 | SMD3030 | SMD3030 |
| PF | >0.95 | >0.95 | >0.95 |
| Beam Angles | 60°/90°/120° | 60°/90°/120° | 60°/90°/120° |
| Driver | Sosen/Meanwell | Sosen/Meanwell | Sosen/Meanwell |
| Options | 1-10V, Daylight Sensor | 1-10V, Daylight Sensor | 1-10V, Daylight Sensor |
| IP Rating | IP65 | IP65 | IP65 |
| Color Temp | 3000K – 6000K | 3000K – 6000K | 3000K – 6000K |
| Working Temp | -20~ +60℃ | -20~ +60℃ | -20~ +60℃ |
| Warranty | 5 years | 5 years | 5 years |
| Material | Aluminum | Aluminum | Aluminum |
Industrial LED luminaires for ceilings and walls
When choosing a luminaire, it is necessary to pay attention to the angle of direction of the light and the method of its diffusion in order to provide a comfortable and bright light for working in the room.
Thanks to the correct calculations, you can use fewer light sources without losing quality and reduce the cost of lighting installation.
- For high spans, it is necessary to buy pendant lights with directional light with aluminum reflectors or methalogen bulbs;
- For low ceilings, wall-ceiling lamps with a wide illumination angle are suitable .
- For public buildings we have emergency luminaires with an exit sign and rechargeable ones.
- For rooms with high humidity and for the street - dust and moisture resistant lamps.
Energy-saving industrial lamps LSP and LPP
Luminaires with LED lamps are rapidly replacing their fluorescent counterparts from industrial lighting. The new models do not require maintenance and replacement of bulbs, and are capable of operating up to 50,000 hours continuously without the risk of failure and consuming a minimum amount of electricity. LSP luminaires have a very high efficiency, and despite the slightly overpriced in comparison with analogs, they can pay off within a few months of active operation.
Advantages of LED Industrial Luminaires
In industrial conditions, replacing a luminaire with a mercury lamp with LED technology will significantly save on lighting. In addition, such products allow you to change the luminous flux and power depending on the requirements, which can be very important in warehouse complexes and industrial areas.
- Due to high efficiency indicators, the load on the network is reduced, and the power can be directed to the operation of other systems;
- LED lamps will last more than 50,000 hours and have a long-term quality guarantee from the manufacturers;
- The payback period of LED lamps does not exceed a period of 1.5-2 years, after which they will begin to bring net profit;
- The degree of protection of the luminaires will protect them from dust, moisture, water and corrosive environments. Here you will find protection classes from IP44 to IP67;
- Flicker-free, which significantly reduces the load on the eyesight of the staff and increases labor productivity;
- Uniform lighting;
- No additional requirements for disposal, since lead and mercury are not used in production.
- First of all, please allow me to introduce our company Ningbo die-casting man to you:
Die-casting Man is one of the lighting manufacturers with design ,development and production. We understand that lighting technology has to be practical,so we always design and develop with our customers needs in mind.
