IK08 Tempered Glass Led Street Light Housing ADC12 IP66 For Outdoor
Price:
Negotiable
MOQ:
10pcs
Delivery Time:
7-35days after deposit
Brand:
Die casting man
Product Description
Product Description
This Led light is a high-performance street lighting available in four sizes:40W/100M/150/200W.
The lunimaire is manufactured from high quality pressure die-casting aluminum.
lt shall have a led efficiency up to 130 lm/w and will be capable of producing.
It up to 26000 luminaire lumens at 4000K finished in Grey or black as standard and 5 years warranty.
Standards & Certification:ENEC,CB,CE,Rohs.
lnstalling Ways:
Both Horizontal and Vertical available and adjustable angle-15°to+15°
Product Specification
| Product Code | YASL-25-40M | YASL-25-100M | YASL-25-150M | YASL-25-240M | ||||||
| Input Wattage | 30W | 40W | 50W | 60W | 100W | 120W | 150W | 200W | 300W | |
| Installation Pipe Diameter | φ45/60mm | φ45/60mm | φ45/60mm | φ45/60/76mm | ||||||
| Luminous Flux | 3900-4500lm | 5200-6000 | 6500-7500lm | 7800-9000lm | 13000-15000lm | 15600-18000lm | 19500-22500lm | 26000-30000lm | 31200-36000lm | |
| Color Temperature | 2700～6500K | |||||||||
| Input Voltage | AC90～305V | |||||||||
| Frequency Range | 50/60Hz | |||||||||
| Power Factor | PF≥0.95 | |||||||||
| color rendering index | Ra≥70 | |||||||||
| Temperature of Working Condition | -40～50℃ | |||||||||
| Humidity of Working Condition | 20%～90%RH | |||||||||
| LED Lifetime | 50000h | |||||||||
| Protectin Grade | IP66 | |||||||||
| Protection level | IK08/09/10 | |||||||||
| Installation Height | 3-6m | 3-6m | 4-6m | 4-8m | 6-10m | 8-12m | 8-12m | 10-14m | 10-14m | |
| Net Weight | 2.9kgs | 2.9kgs | 2.9kgs | 3.8kgs | 3.8kgs | 5.7kgs | 5.7kgs | 7.2kgs | 7.2kgs | |
| Gross Weight | 3.4kgs | 3.4kgs | 3.4kgs | 4.0kgs | 4.0kgs | 6.0kgs | 6.0kgs | 7.5kgs | 7.5kgs | |
| Packing Size(m m) | 555*210*143 | 680*270*160 | 820*320*160 | 920*370*180 | ||||||
Product Size
| Product Code | YASL-25-40M | YASL-25-100M | YASL-25-150M | YASL-25-240M | ||||||
| L(mm) | 555 | 645 | 790 | 890 | ||||||
| W(mm) | 210 | 257 | 305 | 361 | ||||||
| H(mm) | 143 | 147 | 147 | 163 | ||||||
Detail Pictures:
Our Exihibition:
