150W Led Street Light Empty Housing Die Cast Aluminum Ultra High Luminous
Price:
Negotiation
MOQ:
1pc
Delivery Time:
7-40 days base on order quantity
Brand:
Die Casting Man
Product Description
Product Specification:
| Model | SL-25-40M | SL-25-100M | SL-25-150M | SL-25-240M | |||||
| Input Wattage (W) | 30/40/50/60 | 80/100/120 | 150/180/200 | 240/300 | |||||
| Installation Pipe Diameter | φ45/60mm | φ45/60mm | φ45/60mm | φ60/70mm | |||||
| Installation Height (m) | 3-8 | 6-10 | 8-12 | 10-14 | |||||
| Input Voltage | 90~305Vac | ||||||||
| Frequency Range | 50/60Hz | ||||||||
| Power Factor | ≥0.9 | ||||||||
| Light source | LED | ||||||||
| Driver | Inventronics | ||||||||
| Meanwell (optional) | |||||||||
| other brand of driver(upon request) | |||||||||
| Luminaire efficacy (lm/W) | 130-170 | ||||||||
| Color Temperature | 4000 | ||||||||
| Color rendering index | ≥70 | ||||||||
| Diming | Dali (optional) | ||||||||
| 1-10V (optional) | |||||||||
| PWM (optional) | |||||||||
| Smart control management system (upon request) | |||||||||
| The environment temperature | -40～45℃ | ||||||||
| Humidity of Working Condition | 20%～90%RH | ||||||||
| Protectin Grade | IP66 | ||||||||
| Protection level | IK08 | ||||||||
| Standards & Certifications | ENEC | ||||||||
| CB | |||||||||
| CE | |||||||||
| Rohs | |||||||||
| Options | Photocell | ||||||||
| Surge protection | |||||||||
| External cable (length upon request) | |||||||||
| Smart control device | |||||||||
| Materials | Housing: ADC12 die-cast aluminum | ||||||||
| Cover: Toughened Glass | |||||||||
| External Screws: 304 stainless screws | |||||||||
| Color | Grey/Black ( other upon request) | ||||||||
| Model | Product size (mm) | Packing size (mm) | G.W | N.W | |||||
| L | W | H | L | W | H | (kgs) | (kgs) | ||
| YSSL-25-40 | 555 | 210 | 143 | 600 | 260 | 165 | 2.9 | 3.4 | |
| YSSL-25-40M | |||||||||
| YSSL-25-100 | 645 | 257 | 147 | 680 | 270 | 160 | 3.8 | 4 | |
| YSSL-25-100M | |||||||||
| YSSL-25-150 | 790 | 305 | 147 | 820 | 320 | 160 | 5.7 | 6 | |
| YSSL-25-150M | |||||||||
| YSSL-25-200 | 890 | 361 | 163 | 970 | 370 | 180 | 7.2 | 7.5 | |
| YSSL-25-200M | |||||||||
- Luminaire made of die-cast aluminum, closed by tempered glass in order to ensure the IP and protect the characteristics of lenses used.
- Access to electrical components without need of special tools, pressing locking system, which facilitates maintenance. Hidden hinge system.
- Post top or side entry Ø 60 mm with the possibility of adjusting the inclination. Other fixing needs please
- consult.
- Luminaire Class I. Optional Class II
- Luminaire IP66, IK09
- LED version available from 20W to 260W.
- Finished in any RAL color.
- Characteristics of the optical group:
- High performance inner aluminium heatsink
- Number of LED 16-24-32-48-60-80- 96-112
- Lenses Integrated with several asymmetric or symmetric distributions available according to the project needs.
- Luminaire efficacy from 100 to 140lm/W
- Crescent SL-25 series LED street lights provide complete lighting solutions for road and street
-
Full wattage from 30 to 320W, with ultra-high luminous efficiency and various lighting distribution
-
-
Application
It is suitable for the street lighting at highways, urban roads and secondary roads, stadiums, sidewalks, residential areas, industrial areas, squares, parks, schools, villas, gardens and other places.
-
Product Code YASL-25-150M Input Wattage 120W 150W Installation Pipe Diameter φ45/60mm Luminous Flux 15600-18000lm 19500-22500lm Color Temperature 2700～6500K Input Voltage AC90～305V Frequency Range 50/60Hz Power Factor PF≥0.95 color rendering index Ra≥70 Temperature of Working Condition -40～50℃ Humidity of Working Condition 20%～90%RH LED Lifetime 50000h Protectin Grade IP66 Protection level IK08/09/10 Installation Height 8-12m 8-12m Net Weight 5.7kgs 5.7kgs Gross Weight 6.0kgs 6.0kgs Packing Size(mm) 820*320*160 Photometric
DH-T1 DH-T3-M DH-T4-M DY-T3-M GY-T2-M01 GX-T2-M GX-T4-L HX-T2-S DH-T2-L DH-T3-MA DH-T5-M GY-T1-M GY-T3-M01 GX-T3-M HY-T2-M HX-T2-M DH-T2-M DH-T3-MB DY-T2-M GY-T2-M GX-T2-S GX-T4-M HY-T3-M HX-T3-M Product Size
Product Code YASL-25-150M L(mm) 790 W(mm) 305 H(mm) 147 MESSAGE BOARD
