80W LED Street Lighting Fixtures Die-casting Man Environmental for commercial
Price:
Negotiation
MOQ:
10pcs
Delivery Time:
7-30 days base on order quantity
Brand:
Die Casting Man/OEM
Product Description
Economic Street light SL-05-60, max 90W.
Product Description:
| Item NO. | ZHSL-05-40 | ZHSL-05-60 | ZHSL-05-120 |
| Electric current | 700mA | 1300mA | 2450mA |
| LED Quantity | 18pcs | 30 | 60 |
| Rated Power | 42W | 62 | 122 |
| Color Temperature | 3000K/4000K/6500K | 3000K/4000K/6500K | 3000K/4000K/6500K |
| Initial Luminous Flux | 4450/4120/3790LM
| 7160/6630/5370LM | 13420/12997/10528.5LM |
| Input Voltage | AC100-270V | AC100-270V | AC100-270V |
| Frequency Range | 50-60Hz | 50-60Hz | 50-60Hz |
| Power Factor | PF>0.9 | PF>0.9 | PF>0.9 |
| Color Rendering Index | Ra>70-80 | Ra>75-80 | Ra>75-80 |
| Temperature Working Condition | -35℃ - 50℃ | -35℃ - 50℃ | -35℃ - 50℃ |
| Humidity of Working Condition | 20-90% | 20-90% | 20-90% |
| LED Lifetime | 70000h | 70000h | 70000h |
| Protection Grade | IP65 | IP65 | IP65 |
| Installation Pipe Diameter | Φ60mm | Φ60mm | Φ60mm |
| Installation Height | 4-7m | 6-8m | 10-12m |
| Product Dimension | 472mm*238.4mm*101 mm | 645mm*298.4mm*134.8 mm | 863.9*374.4mm*172.1 mm |
| Net Weight | 2.7 kg | 5.5 kg | 9.5 kg |
| Gross Weight | 3.2 kg | 6 kg | 10.5 kg |
| Packing Size | 515mm *280 mm*140mm | 710mm*350mm *130mm | 915mm*420mm*190mm |
We are a professional Die casting factory for around 30years.
If you are importing lighting fixture,of sure our company will be a good option for you since:
1) we can use the material according to your component request.
2) we are die-casting manufacturer for around 30year, we are professional on lighting design and the quality and cost control.
3) we have profession engineer to make sure the design of the housing or the technical date of the product is meet your requirement.
make your idea/drawing to be truth.
4) we are a lighting industrial park,so we can offer the best delivery for you.
5) we have good experience on assembling and exporting lighting fixture for around 10 years,so can offer you very good service.
