5200LM SMD Led Street Lighting Fixtures For Government Project
5200LM SMD Led Street Lighting Fixtures For Government Project
Quick Specification
| Item NO. | ZHSL-09-50 |
| Electric Current | |
| LED Quantity | 24pcs |
| Rated Power | Max.50W |
| Color Temperature | 2700-6500K |
| Initial Luminous Flux | 5200LM |
| Input Voltage | AC85-265V |
| Frequency Range | 50-60Hz |
| Power Factor | PF>0.95 |
| Color Rendering Index | Ra>75-80 |
| Temperature Working Condition | -40℃ - 50℃ |
| Humidity of Working Condition | 20-90% |
| LED Lifetime | 70000h |
| Protection Grade | IP65 |
| Installation Pipe Diameter | 60mm |
| Installation Height | 6-8m |
| Product Dimension | 485x230x98 mm |
| Net Weight | 7 kgs |
| Gross Weight | 8 kgs |
| Packing Size | 52 x25 x21 cm |
| Item NO. | ZHSL-09-100 |
| Electric Current | |
| LED Quantity | 48pcs |
| Rated Power | 100W |
| Color Temperature | 2700-6500K |
| Initial Luminous Flux | 10000LM |
| Input Voltage | AC85-265V |
| Frequency Range | 50-60Hz |
| Power Factor | PF>0.95 |
| Color Rendering Index | Ra>75-80 |
| Temperature Working Condition | -40℃ - 50℃ |
| Humidity of Working Condition | 20-90% |
| LED Lifetime | 70000h |
| Protection Grade | IP65 |
| Installation Pipe Diameter | 60mm |
| Installation Height | 8-10m |
| Product Dimension | 622x292x112 mm |
| Net Weight | 5.4 kgs |
| Gross Weight | 6.2 kgs |
| Packing Size | 67.5 x31.5 x15.5 cm |
Description:
New Patent 30W-100W SMD LED streetlight made of High quality Die Casting Aluminum housing +LG High lumen chip+Meanwell Driver
1. The latest version of high power SMD LED Street Light Housing
2. State-of-art designing with completed die-casting body as heat sink offer the maximum heat management system,which can hold maximum 24-48pcs of 1-5W LG SMD led.
3. Patented anti-glare optic lense enable this street light give an maximum 120 degree light spread,with an asymmetrical polar curve.
4. IP66 protection grade.
5. User-friendly mechanical designing,easy to assemble the led,potic lense and led power supply.
6.The Led power supply is designed to installed with two U brackets,so any brand of led power supply can be easily installed.
Applications:
minor roads,Motorways,Major roads,roundabouts,crossing and industrial areas.
Our service:
your inquiries will be replied in 24 hours in our working days.
- 5years warranty under normal use.
- Professional design provided.
- Timely delivery guaranteed.
