Outside Tool Free 50000h 150w 19500lm Waterproof Street Light
tool free 50000h street light 150w High Power LED Street Light ip66 major road
Product Specification
* Item No.:YASL-19-150
* Input Wattage:150W
* Installation Pipe Diameter:∅60mm
* NW/GW:7.4/8.0kgs
* Packing Size:81*34*15.5cm
Product Specification
| Product Code | ZHSL-19-50 | ZHSL-19-80 | ZHSL-19-150 |
| Input Wattage | 50W | 80W | 150W |
| Color Temperature | 3000-6500K | 3000-6500K | 3000-6500K |
| Luminous Flux | 5500-6250lm | 9200-10400lm | 17250-19500lm |
| Input Voltage | AC90-305V | AC90-305V | AC90-305V |
| Frequency Range | 50/60Hz | 50/60Hz | 50/60Hz |
| Power Factor | PF≥0.95 | PF≥0.95 | PF≥0.95 |
| Color rendering index | Ra≥70 | Ra≥70 | Ra≥70 |
| Temperature of working condition | -40-50℃ | -40-50℃ | -40-50℃ |
| Humidity of working condition | 20%-90%RH | 20%-90%RH | 20%-90%RH |
| LED Lifetime | 50000h | 50000h | 50000h |
| Protection Grade | IP66 | IP66 | IP66 |
| Installation Pipe Diameter | Φ60mm | Φ60mm | Φ60mm |
| Installation Height | 4-6m | 6-10m | 8-12m |
| Net Weight | 3.7kgs | 6.2kgs | 7.4kgs |
| Gross Weight | 4.2kgs | 6.5kgs | 8.0kgs |
| Packing Size(mm) | 620*270*155 | 670*310*155 | 810*340*155 |
| Product Size(mm) | 577*233*103 | 627*271*103 | 768*301*104 |
Main Features
1. High pressure die cast aluminium alloy housing. Anti-corrosion with Electrophoresis process.
2. High performance design with 5050 LED source and exclusive Lens.The light transmittance up to 98%.
Luminous efficacy up to 160-170lm/w
3. Type I,Type II,Type III lens optional. Uniform light distribution apply to different street light project.
4. Excellent operating temperature -40°C ~ 50°C
5. Replaceable and upgradeable modular design easy assembly easy installation and easy maintenance.
6. Green product,no UV or IR radiation,no mercury pollution.Passed IEC62471 test.
7. -15 ~ +15° angle adjustable and applicable different mounting arm.
8. With Excellent housing design reach IP66/IK09 rating.
9. Vibration resistant and Surge protection 10KV/20KV.
10. Easy replacement of the entire LED module and electronic system by removing the top cover.
11. Double Clip on closure,"Plug and Play" system suitable for SKD .
12. LEDs with multi-chips Package has high lumen,stable performance,low light failure and no dead lights.
13. Dimming and smart lighting system available upon request.
14. CE,Rohs,CB,LM-79,LM-80 approved.
15. Life-span over 50,000 hours,5 years warranty.
Trading Conditions
1. Payment term: 30% deposit by T/T and 70% before delivery or against Copy of BL.
2. Delivery time: 25 days
3. Samples time: 7 days.
4. Shipping terms: FOB Ningbo.
5. Discounts will be determined by quantity.
6. Welcome distributors to cooperate together.
FAQ:
A: how many machines do you have?
B: 7 CNC processing machines.
A: How many hour will this machine work a day?
B: 16hours.
A :how about the capacity?
B: around 40,000pcs per month.
A: Are manufacturing work instructions available at working area?
B: yes.our technical department will make a instruction for all of our models. and it will stick on the machines
when they produce the model.
A:can we change the hole position in housing?
B: of course you can.
A:can we watch the painting workshop?
B:due to the time is 7pm in China.the workers got off work.we will show you next time. please pay attention to our Live.
A: what are the procedures of painting will we do?
B: we will polish the die casting part firstly. remove the burrs and make the surface smoothly.
then keep the parts in oven for 15minutes under 185 degree to make it solidify. then the workers
will spray powder on it and hung it on spray line.
