waterproof and dustproof tempering 80w led street light Road lighting fixtures
80w tempering glass LED street light Middle size ZHSL-19-80 with IP66, IK08
Product Description:
| Product Code | ZHSL-19-30 | ZHSL-19-50 | ZHSL-19-80 | ZHSL-19-150 | |
| Input Wattage | 30W | 50W | 80 W | 150W | |
| Color Temperature | 3000-6500K | 3000/4000/6500 | 3000/4000/6500 | 3000/4000/6500 | |
| Luminous Flux | 3300-3750 lm | 5500-6250 lm | 9200-10400 lm | 16500-19500 lm | |
| Input Voltage | AC90-305V | AC 90-305 V | AC 90-305 V | AC 90-305 V | |
| Frequency Range | 50/60Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz | |
| Power Factor | PF≥0.95 | PF≥0.95 | PF≥0.95 | PF≥0.95 | |
| color rendering index | Ra≥70 | Ra≥70 | Ra≥70 | Ra≥70 | |
| Temperature of Working Condition | -40-50℃ | -40--50℃ | -40--50℃ | -40--50℃ | |
| Humidity of Working Condition | 20%-90%RH | 20%-90%RH | 20%-90%RH | 20%-90%RH | |
| LED Lifetime | 50000h | 50000 h | 50000 h | 50000 h | |
| Protectin Grade | IP66 | IP 66 | IP 66 | IP 66 | |
| Installation Pipe Diameter | φ60mm | φ60 mm | φ60 mm | φ70 mm | |
| Installation Height | 4-6m | 4-6 m | 5-8 m | 10-12 m | |
| Net Weight | 3 kgs | 3.5 kgs | 5 kgs | 6.4 kgs | |
| Gross Weight | 3.5 kgs | 4 kgs | 6 kgs | 7.4 kgs | |
| Packing Size | 51*23.6*15 cm | 63*28*15.5 cm | 67*31*16 cm | 82.5834*16 cm | |
Applications:
Motorways,Major roads,minor roads,roundabouts,crossing and industrial areas.
Feature of Product
1.Special optical lens with tempered glass cover,make the good light distribution and perfect proof (water proof and dust proof)
2.With Surge Projector to protect lamp from up to 10KV/10KA.
3. Knob type, easy installation and maintenance by turn the switch do not need tools to open or close the light cap.
4.Full die-cast aluminum housing to prevent guano.
5.The mounting angle is adjustable. The lamp can be adjusted ±15 degree.
6.It can be matched with photocell , smart controller, timer,0-10V dimming,DALI etc
Our advantage
1. Good supply chain management . We have build a good relationship with many international brand ( Bridgelux , San’an , , Osram , Meanwell , , etc). That will help us get high quality led chip, led driver, lens on time.
2. Professional staffs. We have more than 100 staffs.The workers are skilled.They know the products very well from a screw to the whole product. They know the key point during production process and how to deal with if there is a problem.
3. Advanced equipments. We have many advanced equipments. That will make sure that our products are produced in high standard and strict process.
Payment Terms:
1. Samples: Bank TT, 100% payment in advance;
2. Bulk order: Bank TT, 30% deposit and balance 70% settled before shipment.
Warranty: 5 years warranty
Delivery:
- By Express: DHL, UPS, Fedex, a fast and safe way for shipping, normally 3-5 working days for delivery;
2. By Air: In some area, the shipping cost by air is more favorable than by Express; 5-7 days for delivery;
3. By Sea: the most economic shipping method, but cost longer shipping time; large quantity, heavy and not urgent goods can choose this way
FAQ:
Q1.Our project is on seaside, what if your lights be corrosion by sea water?
Metal has high corrosion resistance.Besides, we do best on light surface treatment,
electrostatic spraying and electrophoresis can effectively protect our lights from salt water corrision.
Q2. I really would like to try a sample first ,is that possible?
Yes,that's sure. Our MOQ only 1 pieces,easy know each other better via samples, we look on the long term and win-win cooperation.
Q3. We now have outdoor projects need to do the lighting design,can you help us?
Sure we can, we are the leader of outdoor high power LED light supplier, our design teams can provide you the best solution.
And if you have the tech to make design yourself , we can provide the IES files for you.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 5 years warranty to our products.
