ENEC 80w 3000k Ra70 PF0.95 Ac Led Street Lights
First of all, please allow me to introduce our company Ningbo die-casting man to you,
Die-casting Man is one of the lighting manufacturers with design ,development and production. We understand that lighting technology has to be practical,so we always design and develop with our customers needs in mind.
ENEC 80w 3000k Ra70 PF0.95 Ac Led Street Lights
| Material: | ADC12 Aluminum | Wattage: | 80~120W |
| IP: | 66 | CRI: | ≥70 |
| Color Temperature: | 3000/40000/6500K | Input Voltage: | AC90 - 265V |
| Frequency Range: | 50 - 60Hz | Working Ambient Temperature: | -40℃ - 50℃ |
| Working Ambient Humidity: | 20% - 90%RH | LED Lifetime: | 50000h |
| Part Number: | YASL-25 |
|---|---|
| Production Lead Time: | 7-30 Days |
| MOQ: | 1 PCS |
| Shipping: | EXW / FOB NINGBO |
| Finish Color: | Double gray;Sandy black; |
Prodcut Specification
| Prodcut Code | YASL-25-100 | YASL-25-150 | YASL-25-240 |
|---|---|---|---|
| Input Wattage | 30W/40W/50W | 60W70W80W | 100W120W/150W |
| Color Temperature | 3000/4000/6500K | 3000/4000/6500K | 3000/4000/6500K |
| Luminous Flux | 5750~6250lm | 11500~12500lm | 16500~18750lm |
| Input Voltage | AC90~305V | AC90~305V | AC90~305V |
| Frequency Range | 50/60Hz | 50/60Hz | 50/60Hz |
| Power Factor | PF≥0.95 | PF≥0.95 | PF≥0.95 |
| Color Rendering Index | Ra≥70 | Ra≥70 | Ra≥70 |
| Working Temperature | -40~50℃ | -40~50℃ | -40~50℃ |
| Humidity of Working Condition | 20%~90%RH | 20%~90%RH | 20%~90%RH |
| LED Lifetime | 50000H | 50000H | 50000H |
| Protection Grade | IP66 | IP66 | IP66 |
| Installation Pipe Diameter | φ60mm | φ60mm | φ70mm |
| Installation Height | 4~8m | 6~10m | 8~12m |
| Net Weight | 3.8kgs | 5.7kgs | 7.20kgs |
| Gross Weight | 4.0kgs | 6.0kgs | 7.50kgs |
| Product Size | 680x270x160mm | 820x320x160mm | 920x370x180mm |
YASL-25-150
Is there anything else you want to know about this lamp?
1.Q:What is the waterproof rating?
A:It’s can pass IP66
2.Q:How many years of warranty do you promise?
A:We guarantee the housing for 5 years.for the whole lamp,The warranty of electrical parts is depends on the warranty time of different driver brand.
3.Q:What is the grade of your powder coating?
A:Normal is C2 grade,but If the customer has special request,such as used at the seaside,in this case,we can use phosphating with Akzo powder to reach higher levels,like C3,C4.
4.Q:What's the packing you use?
A:Our packing is PE bags with foam and carton box,we will ensure it safe.
5.Q:What is your usual lead time?
A:25 days for regular products, 10 days extra for special requirements.
Electrical
· Standard AC input of 90-305V,up to 480v available
· EMI filter: 47CFR, part 2, part 15
· Power factor: >0.9
· Total harmonic distortion: <20%
· Surge protection: IEC/EN 61000-4-5 EMC test standard
· Licensed electrician required for installation
Housing
· Rugged, fully sealed, die-cast aluminum housing
· UV-resistant, multi-layer, architectural color, powder coat finish
· High impact, heat resistant, tempered lens
Energy Control Options
· Motion detection available
· Photo sensors available
