ASTM A276 Stainless Steel ESU Round Bar AISI 316LN ESR 1.4429 OD 120MM
Stainless Steel AISI 316LN ESR 1.4429 ESU Round Bar OD 120MM
SS 316LN ROUND BARS & STEEL 316LN ROUND RODS SPECIFICATION
| Grade | Stainless Steel 316LN (UNS S31653) |
| Standard | ASTM A276 / ASME SA276 |
| Diameter | 12mm to 250mm dia |
| Condition | Cold Drawn & Polished Cold Drawn, Centreless Ground & Polished |
| Finish | Bright, Polish & Black |
| Type | Round/Square/ Hexagonal/ Rectangular |
About 316LN stainless steel
316LN (UNS S31653) is a lowcarbon, nitrogen-enhanced version of Type 316 molybdenum-bearing austenitic stainless steel. The Type 316 alloys are more resistant to general corrosion and pitting/crevice corrosion than the conventional chromium-nickel austenitic stainless steels such as Type 304. They also offer higher creep, stress-rupture and tensile strength at elevated temperature. The nitrogen in Type 316LN adds additional resistance to sensitization in some circumstances.
The nitrogen content of Type 316LN stainless steel also provides some solid solution hardening, raising its minimum specified yield strength compared to Type 316L stainless steel. Like Types 316 and 316L, the Type 316LN alloy also offers good resistance to general corrosion and pitting/crevice corrosion.
The chemical composition of grade 316LN stainless steel is outlined in the following table.
| Element | Content (%) |
|---|---|
| Iron, Fe | Balance |
| Chromium, Cr | 16.0-18.0 |
| Nickel, Ni | 10.0-14.0 |
| Molybdenum, Mo | 2.0-3.0 |
| Manganese, Mn | 2.00 |
| Silicon, Si | 1.00 |
| Nitrogen, N | 0.10-0.30 |
| Phosphorous, P | 0.045 |
| Carbon, C | 0.03 |
| Sulfur, S | 0.03 |
Typical Applications
- Orthopaedic implants
- Trauma nails
- Neurological applications
- Surgical instruments
Other Designations
Equivalent materials to grade 316LN stainless steel are given below.
| ASTM A182 | ASTM A213 | ASTM A240 | ASTM A240 | ASTM A276 |
| ASTM A193 (B8MN, B8MNA) | ASTM A312 | ASTM A336 | ASTM A358 | ASTM A376 |
| ASTM A194 (B8MN, B8MNA) | ASTM A403 | ASTM A430 | ASTM A479 | ASTM A666 |
| ASTM A688 | ASTM A813
|
ASTM A814
|
DIN 1.4406
|
DIN 1.4429 |
Applications
Grade 316LN stainless steel is widely used in the following applications:
- Trauma nails
- Orthopedic implants
- Neurological applications
- Surgical instruments
