SAE6150 Spring Steel Round Bar 50CrVA 65mm Diameter 51CrV4 SUP10 ANSI

Price Negotiable
Price: 1.15 USD/KG
MOQ: 100KGS
Delivery Time: 7 Days
Brand: MITTEL TISCO BAO STEEL
Product Description

50CrVA Gade in 65mm Diameter 51CrV4 SUP10 ANSI SAE6150 Spring Steel Round Bar



50CrVA has good mechanical and technological properties and high hardenability. The addition of vanadium refines the grain size of steel, reduces overheating sensitivity, improves strength and toughness, has high fatigue strength and high yield ratio. However, the weldability is poor and the cold deformation plasticity is low. It is a kind of higher grade spring, which is used as an important spring with large section and high load, as well as valve spring, piston spring and ety valve spring with working temperature<300 ºC. Generally, the supply specification of plates is 1.5~10.0MM, which is mostly in the annealed state, and more than 10~30mm is in the non-annealed state. The final heat treatment of medium carbon alloy spring steel is quenching and tempering. After heat treatment, the steel has good toughness, high proportion limit and strength limit, high fatigue strength, similar to the hardenability of 65Si2MnWA, high hardenability and low overheating sensitivity; When the service temperature of the part is 300 ºC, its elasticity can still be maintained. The machinability of steel is good, but the plasticity is low and the weldability is poor during cold deformation.

chemical composition
component C Si Mn P S Cr Ni Mo V
minimum value 0.47 - 0.7 - - 0.9 - - 0.1
Maximum value 0.55 0.4 1.1 0.025 0.025 1.2 0.4 0.1 0.25
Approximate comparison table
GB ISC CNS JIS KS ASTM/AISI UNS ISO DIN EN/DIN W-Nr.
50CrVA A23503 SUP10 SUP10 SPS6 6150 G61500 51CrV4 51CrV4 1.8159



Product Description
Category Grade Diameter
High speed steel 6542,M2,M35,M42 1mm-600mm
Mold steel Cr12,Cr12MoV,Cr12Mo1V1,D2,SKD11,DC53 1mm-600mm
Carbon structure steel Q195, Q215, Q235, Q275 1mm-600mm
Low alloy high strength structure steel Q295, Q345, Q390, Q420, Q460 1mm-600mm
Prime Carbon structure steel 10#, 20#, 35#, 45#, 60#, 20Mn, 65Mn, B2, B3, JM20, SH45,S45C, C45 1mm-600mm
Alloy structure steel 30Mn2, 40Mn2, 27SiMn, 42Crmo,20Cr, 40Cr, 20CrMo, 35CrMo, 20CrMnTi, 30CrMnTi,20MnVB, 20MnTiB, 20CrNiMo, Q345B,
35MnBM,40MnB,36Mn2V, 45MnV,
1mm-600mm
Spring Steel 65Mn, 60Si2Mn, 50CrVA 1mm-600mm
Bearing Steel GCr15, GCr15GD,55SiMoV 1mm-600mm
Structural steels subject to end-quench hardenability requirements 20CrMnTi, 30CrMnTi, 20Cr, 40Cr, 30CrMo, 42CrMoA, 27SiMn, 40Mn2H, 20CrNiMo, 40Mn2, q345b, 35MnBM, 40MnB,45MnV.





Mechanical properties
Diameter (thickness)
d
mm
tensile strength
σb
Mpa
yield pointσs
Mpa
Elongation or elongation after fracture
δ
%
hardness
HBW
d=25(Sample size)
Normalizing or quenching+tempering
≥645
Normalizing or quenching+tempering
≥380
Normalizing or quenching+tempering
≥13
Unheat-treated steel
≤255




Annealed steel
≤217







FAQ

1. Who are we?
Our headquarter is located in WuXi , China. Since 2012, we have sold to North America (60.00%), Western Europe (14.00%) and South America (6.00%). There are about 11-50 people in our office.

2. How do we guarantee quality?
Always provide pre-production samples before mass production;
Always carry out final inspection before shipment;

3. What can you buy from us?
Copper, aluminum, die steel, titanium, customized machine parts
4. Why should you buy from us instead of other suppliers?
The company has 25 years of production experience. It has advanced precision production equipment, modern large warehouse, 200000 tons of inventory goods and a number of long-term stable cooperative customers.

5. What services can we provide?
Accepted delivery conditions: FOB, CFR, CIF, EXW
Accepted payment currency: US dollar, Euro, Japanese yen, Canadian dollar, Australian dollar, Hong Kong dollar, British pound, RMB, Swiss franc;
Accepted payment type: T/T, L/C, D/P D/A, PayPal;
Optional ports: Tianjin, Shanghai, Guangzhou; Shenzhen
Spoken: English, Chinese

6. How can we get your price?
A. We need the following information to quote for you:
1). Product Name
2). standard
3). Material grade (chemical composition)
4). dimension
5). amount
6). Special part drawin
