Product Description
| Product Name | ASME SA 387 GRADE 11 Class 2 alloy Steel Pressure vessel Steel plate |
| Type | chromium-molybdenum alloy steel |
| Process Method | Hot roll, cold roll, cold drawn, ect. |
| Other processing method | Cutting, bending, punching, or as customer's request |
| Size | Thickness from 0.15mm-300mm, width from 50mm-3500mm, length from 1m-12m or according to customer's special request |
| Material grade | GRADE 11 Class 2 |
| Standard | ASME SA387 |
| Surface | mild steel plain finish, hot dip galvanized, color coated, ect. |
| Size Tolerance | +/- 1%~3% |
| Yield Strength | 250~600 MPa |
| Tensile Strength | 350~800 MPa |
| Certificate | API,ISO,SGS,BV,etc |
| Capacity | 5000 tons/month, for non-standard customized products please discuss with us |
| Delivery terms | FOB / CIF / CFR / DAP or discuss with us for other terms |
The higher levels of chromium also provide excellent corrosion and oxidation resistance, which is a must in sour gas applications. Please refer to our technical specifications below for ASME SA387 Grade 11 Class 2.
Equivalents
| BS | EN | ASTM/ASME | DIN |
| 621 B | --- | SA387-11-2 | --- |
Specifications for ASME SA387 Grade 11 Alloy Steel Plates
| Designation | Nominal Chromium Content (%) |
Nominal Molybdenum Content (%) |
| SA387 Grade 11 | 1.25% | 0.50% |
Tensile Requirements for ASME SA387 Grade 11 Alloy Steel Plates Class 2 Plates
| Designation: | Requirement: | Grade 11 |
| SA387 Grade 11 | Tensile strength, ksi [MPa] | 75 to 100 [515 to 690] |
| Yield strength, min, ksi [MPa]/(0.2% offset) | 43 [310] | |
| Elongation in 8 in. [200mm], min % | 18 | |
| Elongation in 2 in. [50mm], min, % | 22 | |
| Reduction of area, min % | --- |
Chemical Requirements for ASME SA387 Grade 11 Alloy Steel Plates
| Element | Chemical Composition (%) | |
| SA387 Grade 11 | ||
| Carbon: | Heat Analysis: | 0.05 - 0.17 |
| Product Analysis: | 0.04 - 0.17 | |
| Manganese: | Heat Analysis: | 0.40 - 0.65 |
| Product Analysis: | 0.35 - 0.73 | |
| Phosphorus: | Heat Analysis: | 0.035 |
| Product Analysis: | 0.035 | |
| Sulphur (max): | Heat Analysis: | 0.035 |
| Product Analysis: | 0.035 | |
| Silicon: | Heat Analysis: | 0.50 - 0.80 |
| Product Analysis: | 0.44 - 0.86 | |
| Chromium: | Heat Analysis: | 1.00 - 1.50 |
| Product Analysis: | 0.94 - 1.56 | |
| Molybdenum: | Heat Analysis: | 0.45 - 0.65 |
| Product Analysis: | 0.45 - 0.70 |
