Hot Rolled CS Round Bar 20 MM X 6000 MM Grade S355JR S355J2 EN 10084 2008
Hot Rolled CS Round Bar 20 MM X 6000 MM Grade S355 JR S355J2 EN 10084 : 2008
S355J2 is carbon manganese, high yield non alloy steel. It is called S355 because of the average minimum yield for this material is 355 Mpa.
S355J2 1.0577 Carbon Steel Rod has excellent strength and weldability. It can be easily welded to other weldable steel.
Due to its low carbon equivalent EN 10250 S355j2 Structural Steel Square Bar it provides good cold-forming properties and it is generally supplied in a normalized condition.
S355J2 Round Bar is often used for application which requires better mechanical properties than that of S275 grade. It is commonly supplied in as rolled condition and it is widely used in the construction, manufacturing and offshore industries.
S355J2 square bar can be supplied with a variety of treatments and test options to ensure that it is a highly usable steel in your various projects.
S355J2+N round bar have the properties to adopt brittle layer over its top and thus it can easily resist temperature attack. Thus it has higher temperature resistance and higher heat resistance.
According toEN10025:1990, S355J2G3 round bar is a non-alloy structural steel. This standard has now been replaced by EN10025-2:2004 and steels with the S355J2G3 designation are now known as S355J2.
EN 10277 S355J2G3 Hex Bar is carbon manganese steel. It is characterized by its excellent weldability and strength.
BS EN 10025-2 S355J2+N Rod is often used in the most demanding environments such as the offshore industry. It has excellent chemical and physical properties
1.0577 S355J2 Steel Flat bar are used primarily by fabrication customers and it finds many applications in structures and frames. It can be easy to cut and drill, which is why they are particularly suited to welding.
BS EN 10250 10025 S355J2 Black Bar applications include machinery parts, axles, bolts and connecting rods, motor, hydraulic and pump shafts, etc.
Table Of Content
- S355J2 Carbon Steel Round Bar Specification List
- Price List of S355J2 1.0577 Carbon Steel Rod
- Types of S355J2 z35 Bar
- 1.0577 S355J2 Steel Flat bar Chemical Compostion
- Mechnical Propeties of BS EN 10250 10025 S355J2 Black Bar
- S355j2 Round Bar Equivalent
- Tolerance of BS EN 10025-2 S355J2+N Rod
- Surface Finish of 1.0577 S355J2 Steel Flat bar
S355J2 Carbon Steel Round Bar Specification List
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 5 mm To 500 mm |
| Diameter | 0.1 mm to 100 mm |
| Length | 100 mm To 6000 mm Long & Above |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | Round, Square, Hex (A/F),Flate, Rectangle, Billet, Ingot, Forging Etc. |
| Stainless Steel | ASTM A-479, A-182, 304, 304L,304H,304S, 316, 316L,316 Ti, 316H, 309, 310, 310S, 317L, 321, 347, 409, 410, 420, 430, 440, 446, 904L. etc. |
| Duplex Steel | 2205, 31803, 32750, 32760, 2101, 2304. |
| Alloy Steel | A-182 - F5, F9, F11, F12, F21, F22 & F91 |
| Special Grade | Stainless Steel 17-4 PH, Alloy 800, Alloy 600. Hastelloy C276. |
| Carbon Steel | A 105, LF 2, Duplex Steel. |
1.0577 S355J2 Steel Flat bar Chemical Compostion
| Carbon Steel | C | Si | Mn | P | S | C.E. |
| S355J2+N | max 0.22 | max 0.55 | max 1.60 | max 0.035 | max 0.035 | max 0.047 |
Mechnical Propeties of BS EN 10250 10025 S355J2 Black Bar
| Thickness (mm) | Yield Strength Rehmin (N / mm²) | Tensile Strength Rmmin (N / mm²) | Elongation A5 min(%) | Impact Values Charpy-V-Notch Longitudinal Average from 3 Speimens Thk.>10 < 150mm. |
| 3<thk<100 | 355-550 | 490-630 | max 22 | 27 Joules at -20 C |
| USA | Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Italy UNI |
European old EN |
Sweden SS |
Czechia CSN |
| A656 | 1.0577 ASt52 St52-3N |
SS490YA | A52FP | 224-460 | S355J2G4 | Fe510D2 S355J2G4 |
2134-01 | 11531 |
Tolerance of BS EN 10025-2 S355J2+N Rod
| Form of Supply | Size(mm) | Length(mm) |
| Round bar | Φ140-Φ1000 | 3000-10000 |
| Square bar | 100 x 100-600x600 | 3000-6000 |
Flat bar/Blcoks |
Thickness :120-800 | 2000-6000 |
