EN10025 S355JR Steel Plate Width 1200 MM X Length 3000 MM X 90 MM Thickness
EN10025 S355JR Steel Plate Width 1200 MM X Length 3000 MM X 90 MM Thickness
| Product Details | |
| Width | 1500-4050mm |
| Wall thickness | 8mm-300mm |
| Length | 3000MM-15000MM |
| Internatioanal Standard | ISO 9001-2008 / ISO 630 / JIS / ASTM |
| Standards | ASTMA53/ASTM A573/ASTM A283/Gr.D/ BS1387-1985/ GB/T3091-2001,GB/T13793-92, ISO630/E235B/ JIS G3101/JIS G3131/JIS G3106/ |
| Materials | AH32/36,DH32/36,EH32/36,ABS Grade A/B/C/D/E, TU1/20g0Cr13Ni5Mo/Q235A 0Cr13Ni5Mo/16Mn,Q345R,Q245R |
| Product Category | Metallurgy,Mineral &Energy |
| Technique | Hot Rolled |
| Packing | 1.Big OD:in bulk 2.Small OD:packed by steel strips 3.woven cloth with 7 slats 4.according to the requirements of customers |
| Usage | Mechanical&manufacture,Steel strcuture, Shipbuilding,Bridging,Automobile chassis |
| Main market | Middle East,Africa, Asia and some Uropean country and America ,Australia |
| Country of origin | China |
| Productivity | 15000 Metric Tons per Month |
| Remark | Payment terms :T/T ,L/C Terms of trade :FOB ,CFR,CIF ,DDP,EXW Minimum order : 1 Ton Lead time :on or before 3-15 working days . |
| Logo | Changzeng shipping mark or your company logo |
| Another Name | Hot rolled mild carbon steel plate, carbon steel plate ,steel plate |
| Surface processing | You can Galvanized,coated,or as your request |
| Technical | Hot rolled mild steel |
| you Can | Customized Sizes, Galvanized And punching |
S335JR - an useful structural grade steel with a minimum yield strength of 355 N/mm². S355 being widely used in the structural engineering and construction industries, S355 offers high yield and tensile strength and is supplied with a variety of treatments and test options to ensure that it is a highly usable steel in your various projects.
S355 structural grade (S) carries minimum yield strength of 355 N/mm²m, the JR designation confirms that the steel has undergone longitudinal Chary V-Notch impact testing at 27J (Joules) at room temperature. Other Charpy designations include J0, J2 and K2.
These grades of steel are intended for structural work where no significant forming or bending must be done. These grades can be bolted,riveted and welded in a full range of structural and fabricated items including bridges, box girders, cranes and other general structural projects.
The grade designations of SANS 50025 / EN10025-2 refer to the minimum yield strength of each grade for thicknesses less than or equalto 16mm. The steel should be selected in accordance with the strength requirements.The JR, J0 & J2 suffixes refer to different impact requirements. An average impact energy value of 27 Joules must be achieved on full size specimens in the longitudinal direction in all applicable cases.
| Grade | Max C content for t in mm | Mn max | Si max | P max | S max | Cu max | N max | ||
| t ≤ 16 | >16 t ≤ | t >40 | |||||||
| S275JR | 0.21 | 0.21 | 0.22 | 1.5 | - | 0.035 | 0.035 | 0.55 | 0.012 |
| S355JR | 0.24 | 0.24 | 0.24 | 1.6 | 0.55 | 0.035 | 0.035 | 0.55 | 0.012 |
| S355JO | 0.20 | 0.20 | 0.22 | 1.6 | 0.55 | 0.035 | 0.035 | 0.55 | 0.012 |
| Grade | Yield (MPa)min | Tensile (MPa)min | Charpy V - notch longitudinal | |
| Strength at t = 16mm | Temp ( °C) | Energy (J) t =16mm | ||
| S275JR | 275 | 410/560 | 20 | 27 |
| S355JR | 355 | 470/630 | 20 | 27 |
| S355JO | 355 | 470/630 | 0 | 27 |
| Grade | Thickness (mm) | Min Yield (Mpa) | Tensile (Mpa) | Elongation (%) | Min Impact Energy | |
| S355JR | 8mm-100mm | 315Mpa-355Mpa | 450-630Mpa | 18-20% | 20 | 27J |
| 101mm-200mm | 285-295Mpa | 450-600Mpa | 18% | 20 | 27J | |
| 201mm-400mm | 275Mpa | - | 17% | 20 | 27J | |
S355 JR Steel Plate Grade and Specification:
- Thickness: 1-200mm
- Width: 1000-1500mm
- Length: 1000-12000mm
- Material: Q235B,Q345B,S235JR/S235/S355JR/S355,SS440/SM400A/SM400B
- Standard: EN 10025-2:2004
- Technique:Hot Rolled
- Steel Number:1.0045
- Export To:Saudi arabia, Kuwait, Qatar, Oman, Yemen, UAE, Iran, Turkey, Kazakhstan, Greece, Singapore, Thailand, Indonesia, Vietnam, South Africa,South America,Brazil, India, Australia, Egypt.
Our Advantage:
1. We deal with steel products for over 14 years.
2. We mainly supply steel products for the construction industry and manufacturing industry.
3. We have longterm cooperation with most of the state-owned factories and famous private factories.
4. We can provide all kinds of steels such as pipes, sheets, plates, bars, coils, beams and sectiongs; We also supply all the steel materials such as carbon steel, stainless steels, alloy steels.
FAQ:
1. How can we guarantee quality?
Our company are specialized in steel field for over more than 14 years
