UNS: S43900
EN-DIN: 1.4510

439 Oxidation resistance and corrosion resistance is superior to Type 409 in areas where temperatures may exceed the oxidation limit of Type 409 or where aqueous corrosion resistance, particularly to chlorides, is needed. Applications include: Tubular manifolds and other exhaust system with difficult to form exhaust components.

Nominal Composition

Physical Properties
At 70°F (At 20°C)

Density
0.278 lb./in³ / (7685 kg/m³)

Modulus of Elasticity (E)
28.4 x 10³ ksi / (193 x 10³MPa)

Electrical Resistivity
24.0 μ ohm.in / (60.0 μ ohm.cm)

Applicable Specifications

ASTM A240

Typical Mechanical Properties – Typical Room Temperature Mechanical Properties

Typical mechanical properties are based on AK source, ASTM A240

Condition
Annealed

Tensile Strength (UTS)
66 ksi (455 MPa)

0.2% YS
43 ksi (296 MPa)

Elongation% in 2” (50.8 mm)
32%

Hardness Rockwell
74 HRBW
