Stainless Steel Welded Tube 14", CON COSTURA, ASME B36.19M, SCH 10, BE, ASTM A312 GR. TP304
Stainless Steel Welded Tube 14", CON COSTURA, ASME B36.19M, SCH 10, BE, ASTM A312 GR. TP304
| Commodity | Manufacturer 201 304 316 321 Welded Polished Seamless Steel Tube Round Stainless Steel Pipe |
Standards | ASTM / ASME,GB,DIN, JIS,T14975, etc |
Steel Grade | 200 (Ni : 0.8%), 201B (Ni : 3%) , 201H (Ni : 5%) , 301 (Ni :6%), 303, TP304, TP304L/304L, 321 ,TP321, 316, TP316L, 316L, 316Ti, 317, 317L, 309S, 310S(2520), 347, Duplex 2205, Duplex 2207,etc |
| Out Diameter | 0.1-4500mm |
| Wall Thickness | 0.01~250mm |
Length | 5.8m or according to clients' requirements |
Tolerance | Out diameter : +/-0.15mm Thickness: +/-11% of wall thickness Length: +/-4.5mm - 0mm |
Surface | Mirror Polish,Satin Polish,Without Polish,NO.1,NO.4,bright finish |
MOQ | 1 ton |
Supply ability | 5000 Ton/Tons per Month |
Packing | 1, With plastic cap to protect both ends 2, Plastic bag wrapped outside the pipe 3, Bundles to be covered by polythene & strapped securely 4, If require, the pack into wooden box |
Payment terms | L/C at sight,T/T(30% deposit), etc. |
Delivery terms | FOB/CFR/CIF |
Delivery time | Within7-10 days after received 30% deposit |
Certificate | ISO 9001 and third party inspection, SGS,BV |
| Chemical Composition (%) | ||||||||
| Grade | C | Mn | Si | Cr | Ni | P | S | Mo |
| 201 | ≤0.15 | 5.5-7.5 | ≤0.75 | 16.0-18.0 | 3.5-5.5 | ≤0.06 | ≤ 0.03 | |
| 304 | ≤0.08 | ≤2.0 | ≤1.0 | 18.0-20.0 | 8.0-10.5 | ≤0.045 | ≤ 0.03 | |
| 304L | ≤0.03 | ≤2.0 | ≤1.0 | 18.0-20.0 | 9.0-13.0 | ≤0.045 | ≤ 0.03 | |
| 304H | 0.04-0.10 | ≤2.0 | ≤0.75 | 18.0-20.0 | 8.0-10.5 | ≤0.045 | ≤ 0.03 | |
| 304N | ≤0.08 | ≤2.0 | ≤0.75 | 18.0-20.0 | 8.0-10.5 | ≤0.045 | ≤ 0.03 | |
| 305 | ≤0.12 | ≤2.0 | ≤0.75 | 17.0-19.0 | 10.5-13.0 | ≤0.045 | ≤ 0.03 | |
| 309 | ≤0.20 | ≤2.0 | ≤0.75 | 22.0-24.0 | 12.0-15.0 | ≤0.045 | ≤ 0.03 | |
| 309S | ≤0.08 | ≤2.0 | ≤0.75 | 22.0-24.0 | 12.0-15.0 | ≤0.045 | ≤ 0.03 | |
| 310S | ≤0.08 | ≤2.0 | ≤1.5 | 24.0-26.0 | 19.0-22.0 | ≤0.045 | ≤ 0.03 | |
| 314 | ≤0.25 | ≤2.0 | 1.5-3.0 | 23.0-26.0 | 19.0-22.0 | ≤0.045 | ≤ 0.03 | |
| 316 | ≤0.08 | ≤2.0 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | ≤0.045 | ≤ 0.03 | Mo 2.0-3.0 |
| 316L | ≤0.03 | ≤2.0 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | ≤0.045 | ≤ 0.03 | Mo 2.0-3.0 |
| 316N | ≤0.08 | ≤2.0 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | ≤0.045 | ≤ 0.03 | Mo 2.0-3.0 |
| 316Ti | ≤0.08 | ≤2.0 | ≤1.0 | 16.0-18.0 | 10.0-14.0 | ≤0.045 | ≤ 0.03 | Mo 2.0-3.0 Ti 0.2-0.7 |
| 317L | ≤0.03 | ≤2.0 | ≤0.75 | 18.0-20.0 | 11.0-15.0 | ≤0.045 | ≤ 0.03 | |
| 321 | ≤0.08 | ≤2.0 | ≤0.75 | 17.0-19.0 | 9.0-12.0 | ≤0.045 | ≤ 0.03 | |
| 321H | 0.04-0.10 | ≤2.0 | ≤0.75 | 17.0-19.0 | 9.0-12.0 | ≤0.045 | ≤ 0.03 | |
| 329 | ≤0.08 | ≤1.00 | ≤0.75 | 23.0-28.0 | 2.0-5.0 | ≤0.04 | ≤0.03 | |
| 347H | 0.4-0.10 | ≤2.0 | ≤0.75 | 17.0-19.0 | 9.0-13.0 | ≤0.045 | ≤ 0.03 | |
| 409 | ≤0.08 | ≤1.0 | ≤1.0 | 10.5-11.75 | 0.50 | ≤0.045 | ≤ 0.03 | |
| 410 | ≤0.15 | ≤1.0 | ≤1.0 | 11.5-13.5 | 0.75 | ≤0.04 | ≤0.03 | |
| 430 | ≤0.12 | ≤1.0 | ≤1.0 | 16.0-18.0 | 0.75 | ≤0.04 | ≤0.03 | |
| 17-4PH | ≤0.07 | ≤1.0 | ≤1.0 | 15.5-17.5 | 3.0-5.0 | ≤0.04 | ≤0.03 | |
| 17-7PH | ≤0.09 | ≤1.0 | ≤1.0 | 16.0-18.0 | 6.5-7.75 | ≤0.04 | ≤0.03 | AL 0.75-1.5 |
| 904L | ≤0.02 | ≤2.0 | ≤1.0 | 19.0-23.0 | 23.0-28.0 | ≤0.045 | ≤0.035 | |
| 2205 | ≤0.03 | ≤2.0 | ≤1.0 | 22.0-23.0 | 4.5-6.5 | ≤0.03 | ≤0.02 | |
| 2507 | ≤0.03 | ≤1.0 | ≤0.8 | 24.0-26.0 | 6.0-8.0 | ≤0.035 | ≤0.02 | |
Packing | Each tube is wrapped in a plastic sleeve with a cap on the end to ensure the best cleanliness |
OEM accepted, besides,the pakage can also be according to your demands. | |
Shipping | 1.Shipping by containers |
2.Shipping by bulk ship. |
Q1. How do you control quality ?
A1: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS
Q2: What is the terms of packing?
A2: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers requirement.
Q3:What is your delivery time?
A3: For stocks, we could transport the goods to loading port within 7 days after we received your deposit
For production period, it usually takes about 15 days-30 days after receiving the deposit.
Q4. What are the advantages of your company ?
A4: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q5. How many coutries you already exported ?
A5: Exported to more than 100 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.
Q6. Can you provide sample ?
A6: We can provide the samll samples in stock for free, as long as you contact us.
Customized samples will take about 5-7days.
