Carbon Steel Plate Q235B S235JR Steel sheet 4x1000x4000 S235JRG2 EN 10025-2
Carbon Steel Plate Q235B S235JR Steel sheet 4x1000x4000 S235JRG2 EN 10025-2
| Material Grade | Q195,Q215 A,Q215 B,Q235 A,Q235 B,Q235 C, Q235D,Q275,Q275B,Q275C,Q275D,Q295,Q345,Q390,Q420, Q460, SS330,SS400,SS490,SS540,A36,1,GR.36,50(245),55(380),42(290), 60(415),65(450),S185(1.0035),S235JO(1.0114), S235JR(1.0038), S235J2(0.0117),S275JR(1.0044),S275JO(1.10143),S355JO(1.0553), E295(1.0050),E335(1.0060), S235J2W(1.861),S355J2W(1.8965),10#, 15#20# |
| Standard | GB,ASTM,DIN,JIS,NF,BS,ISO,ROCT |
| Thickness | 0.1mm-300mm or as required |
| Width | 1000-5000mm,such as 1220mm 1250mm 1500mm (as customer's required) |
| Length | 1-12m,such as 2440mm 2500mm 3000mm or as required |
| Surface | Black painting, varnish paint, anti rust oil, hot galvanized, cold galvanized, 3PE,ect |
| Technique | Hot Rolled /Cold Rolled |
| Application | Ship building Industry , building construction,bridge, architecture,pressure vessel steel,etc. |
| Trade Terms | EXW,FOB,CIF CFR |
| Loading Port | Shanghai port |
| Payment terms | 1) 30% deposit by T/T, the balance against copy of B/L by T/T. |
| 2) 30% deposit by T/T, the balance by L/C at sight. | |
| 3) 100% L/C at sight. | |
| MOQ | 1Ton |
| Packing Detail | Standard Seaworthy Package or customer requirements |
| Delivery time | 1.Usually,within10-20days after receiving deposit or LC. 2.According to the order quantity |
| Samples | Free samples are provided but the fright is borne by the buyer |
Our steel plate products into high-strength low-alloy steel Plate, carbon structural steel plate, alloy structural steel plate, boiler and pressure vessel steel plate, bridge steel plate, structural steel plate, shipbuilding and marine oil platform steel plate, pipe steel plate, high strength and high toughness steel plate, mold plate, corrosion-resistant plate, composite plate with 12 major series.
Size range: Plate width 1500-4020mm, thickness 6-700mm, length 3000-18800mm.
Delivery status: According to the requirements of users, according to hot rolling, normalizing, tempering, normalizing plus tempering, quenching and other delivery.
Standard: According to user requirements, can be delivered the following criteria: National standards, the metallurgical industry, the American ASTM, ASME standards, Japanese JIS, German DIN, British BS, European EN, the international ISO standards and the standards specific board.
|
|
Thickness (mm) |
width(mm) |
Length(M) |
Cold rolled steel plate |
0.2-4.0mm |
500-2200mm |
As client requirement |
Hot rolled steel plate |
2.0-100mm |
500-2200mm |
As client requirement |
ITEM |
Carbon steel plate |
STANDARD |
ASTM A36/A36M, ASTM A285, ASTM A283, EN10025-2-2004, ASTM A572, ASTM A529,ASTM A573, ASTM A633, JIS G3101-2004, ASTM A678 ASTM A588, ASTM A242,etc |
MATERIAL |
A36, SS400, Q235, Q345, Q195, Q215, S185, SM400, A283 Gr.A,Gr.B,Gr.C, A285 Gr.A,Gr.B,Gr.C, S235J0, S235JR, S235J2, Q275, S275JR, S275J0, E295, SS490, SS540, S355J0, SM570, E335, S235J2W, Q355, SMA490, S355J2W, Q265, P235GH, SB410, SPV235, SGV410, SG255, P265GH, SB450, SG295, P295GH,etc. |
SIZE |
Thickness: 6.0-400mm
|
SURFACE |
Black painted,PE coated,Galvanized ,etc |
EXPORT TO |
India,Dubai,Peru,Saudi Arabia,Indonesia,Singapore,Korea,Viet Nam,Thailand,Brazil,
|
APPLICATION |
Steel plates are widly used as boiler plate, container plate, flange plate and ship plate, andwidly used in building construction. The size of steel plate can be made according toclients requirements. |
A carbon steel plate has usually been considered as the steel that does not contain much alloy steel elements, also named as mild steel. Generally, elements are C, Mn, P, S, Si, besides these, there are no minimum limits for elements of Al, Cr, Ni, Mo, V, etc.
Carbon steel plates are available in different grades depending on the carbon content and strength.
As the content of Carbon increase, the steel plate hardness increases.
Low carbon steel plate: For carbon content 0.06% to 0.25%, also we call it mild steel plate.
Medium carbon steel plate: C content from 0.25% to 0.55%.
High carbon steel plate: 0.55% to 1.0%, also called hard steel plate.
Low carbon steel is the most common form, and it's very malleable and ductile. Medium carbon steel balances ductility as well as strength for excellent wear resistance. High carbon steel is exceptionally strong, while ultra-high carbon steel can be tempered to even greater hardness but no malleability.
Mild steel is a type of carbon steel with a low amount of carbon - it is actually also known as "low carbon steel." Mild steel is not an alloy steel and therefore does not contain large amounts of other elements besides iron; you will not find vast amounts of chromium, molybdenum, or other alloying elements in mild steel. Less carbon means that mild steel is typically more ductile, machinable, and weldable than high carbon and other steels, however, it also means it is nearly impossible to harden and strengthen through heating and quenching.
Mild steel sheet plate is so versatile. It is tough, strong and stiff. It is ideal for welding and painting, can be easily machine cut and drilled and is magnetic. Our customers have used it for myriad applications including automotive repairs, engineering patch up jobs and many other DIY projects.
Standard |
Grade |
C max |
Mn max |
Si max |
P max |
S max |
Yield strength max |
Tensile strength |
Elongation% |
JISG3101 |
SS400 |
0.22 |
1.40 |
0.50 |
0.035 |
0.035 |
245 |
400-500 |
26 |
ASTM |
A36 |
0.25 |
0.80-1.20 |
0.40 |
0.045 |
0.050 |
250 |
400-520 |
26 |
ASTM |
A283 |
0.14-0.24 |
0.90 |
0.40 |
0.035 |
0.040 |
210 |
310-510 |
22-27 |
GB700 |
Q235A |
0.14-0.22 |
0.30-0.65 |
0.30 |
0.045 |
0.050 |
235 |
370-460 |
21-26 |
GB700 |
Q235B |
0.22 |
0.30-0.65 |
0.30 |
0.045 |
0.045 |
235 |
375-460 |
21-26 |
GB700 |
Q235C |
0.18 |
0.30-0.80 |
0.30 |
0.040 |
0.040 |
235 |
375-460 |
21-26 |
GB700 |
Q235D |
0.17 |
0.35-0.80 |
0.35 |
0.040 |
0.035 |
235 |
375-460 |
21-26 |
EN10025 |
S235JR |
0.17 |
0.65 |
0.35 |
0.030 |
0.030 |
225 |
360-510 |
18 |
Structural Grade
ASTM A-36 is a structural quality carbon steel plates for use in welded or bolted construction of bridges and buildings, and for general structural purposes. Minimum yield strength of 36 ksi (250 MPa) is required to meet the requirements of A36. ASTM A36 plate is used in a variety of applications, which include, but are not limited to: railroad cars, trucks, agriculture equipment, trailers, construction equipment, buildings and bridges.
High Strength/Low Alloy
High-strength low-alloy steel (HSLA) is a type of alloy steel that provides greater resistance to corrosion than carbon steel. HSLA steels are not made to meet a specific chemical composition but rather to specific mechanical properties.
Item |
steel plate,steel sheet,mild steel sheet,carbon steel sheet |
|
Standard |
ASTM A36 / A36M |
|
Thick Chemical |
≤20 |
C≤0.25, Si≤0.40, P≤0.040, S≤0.050, Rm:400-550Mpa |
20-40 |
C≤0.25, Si≤0.40, Mn:0.80-1.20, P≤0.040, S≤0.050, Rm:400-550Mpa |
|
40-65 |
C≤0.26, Si:0.15-0.40, Mn:0.80-1.20, P≤0.040, S≤0.050, Rm:400-550Mpa |
|
65-100 |
C≤0.27, Si:0.15-0.40, Mn:0.85-1.20, Rm:400-550Mpa |
|
>100 |
C≤0.29, Si:0.15-0.40, Mn:0.85-1.20, Rm:400-550Mpa |
|
Thickness |
0.3-500mm |
|
Width |
100-3500mm |
|
Length |
2m, 2.44m, 3m, 6m, 8m,12m, or rolled,etc |
|
Surface |
Black painted, PE coated, Galvanized, Color coated ,etc |
|
Package |
Standard export package, suit for all kinds of transport, or as required. |
|
Container Size |
20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High)
|
|
Price term |
Ex-Work, FOB, CNF, CFR, CIF, FCA, DDP, DDU,etc |
|
Payment term |
TT, L/C, Western Union |
|
MOQ |
1000Kg |
|
Export to |
Ireland,Singapore,Indonesia,Ukraine,Saudi Arabia,Spain,Canada,USA,Brazil,Thailand,
|
|
Application |
steel plate are widely used in shipping building,engineer construction, mechanical manufacturing,the size of alloy steel sheet can be made according to clients required. |
|
Contact |
If you have any question, please feel free to contact me.
|
|

1. CAN I GET SOME SAMPLES?
Yes. We can provide samples, you need to pay the sample fee and shipping cost in advance.
We will refund the sample fee after you place your order.
Please let us know your courier account or send us your fees and we will arrange to send you a sample.
2. CAN YOU PRODUCE ACCORDING TO THE SAMPLES?
Yes, we can produce your samples or technical drawings. We can build the molds and fixtures.
3. WHAT IS YOUR TERMS OF PAYMENT?
Payment<= 1000 USD, 100% in advance.
Payment>= 1000 USD, 30% T/T in advance, balance before shipment.
If you have another question, pls feel free to contact us ASAP.
4. WHAT IS YOUR TERMS OF DELIVERY?
EXW, FOB, CFR, CIF, DDU.
5. CAN WE VISIT YOUR FACTORY?
Warmly welcome. Once we have your schedule, we will arrange for the professional sales team to follow up on your case.
6. HOW ABOUT YOUR DELIVERY TIME?
Generally speaking, 10 to 25 days after receiving your advance payment. The exact delivery time depends on the goods and quantity you ordered.
7. AFTER-SALE ADVANTAGES.
Year warranty for products; If you find any defective parts for the first time, we will provide you with new parts for free in the next order. As an experienced manufacturer, you can be assured of quality and after-sales service.
For more product details and the latest prices, please contact me now.
