ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm
ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm
Specification And Material Grade Of Incoloy 825 Plate
| ASME/ASTM Name | ASTM B424 / ASME SB 424 |
| size in mm | 2000 mm x 4000 mm, 1220 mm x 2440 mm, 1000 mm x 2000 mm, 2000 mm x 2000 mm, 1500 mm x 3000 mm, |
| Thickness of Standard Plate | 0.1 to 12 mm Thick |
| Most Frequently Used Form | Strip, Flats, Rolls, Ring (Flange), Coils, Foils, Shim Sheet, Blank (Circle), Plain Sheet |
| Different Finish | Cold rolled sheet (CR), 2B, Hot rolled plates (HR), BA NO(8), SATIN (Met with Plastic Coated), 2D, |
| Hardness Range | Half Hard, Soft, Quarter Hard, Spring Hard, Hard etc |
Minimum Yield Strength Chart Of Astm B424 UNS N08825 Strip
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
Chemical Structure Of 2.4858 Coils
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
Equivalent Table Of JIS NCF 825 Plates
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 825 | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 | NFE30C20DUM | NiCr21Mo |
What types of high-temperature alloy products do you offer?
We offer high-temperature alloy rods, wires, strips, plates, tubes, bolts, and nuts. Our products cover various specifications and sizes to meet different application needs.
How to choose the right high-temperature alloy material?
Choosing the right high-temperature alloy material requires a comprehensive consideration of factors such as the temperature, corrosiveness, and mechanical strength requirements of the specific application environment. Our engineers can provide professional advice to help you select the most suitable material.
What international standards do your high-temperature alloy products meet?
Our products meet international standards such as ASTM, AMS, GB/T, ensuring product quality and reliability.
Can you customize products according to customer requirements?
Yes, we offer customized services based on the specific needs of our customers, including special specifications and performance requirements.
What are your production processes and quality control like?
We use advanced production processes and a strict quality control system. From raw material procurement to the final product shipment, every step is carefully monitored to ensure the product quality meets the standards.
Can you provide samples?
Yes, we can provide samples according to your requirements.
