1.5mm 4.0mm 8.0mm 316L stainless steel coil for heat exchanger, food industry
1.5mm 4.0mm 8.0mm 316L stainless steel coil for heat exchanger, food industry
Quick Detail
316L stainless steel coils
size: 1000mm 1219mm 1500mm(we also have mile edge coils in stock)
Brand: TISCO BAOSTEEL ZPSS JISCO.etc
Surface: original surface 2B NO.1, we can make the surface treatment like: BA NO.4 mirror 8K .etc
we have about 6-8 coils for each size.
Description
TISCO 1.5mm 4.0mm 8.0mm 316L stainless steel coil, grade 316L ss coils
About our 316L stainless steel coil
| Material | 316L |
| Size | width:500-1800 mm thickness: 3.0 -120mm |
| Surface |
original surface is NO.1 2B , we can make surface treatment like: BA NO.4 mirror and pvc coat |
| Brand | TISCO JISCO BAOSTEEL POSCO.etc |
| packing | standard export seaworthy packing or as customer required. |
we are the agent of TISCO in wuxi city, we can supply all size of stainless steel plate, the common size of our coils is 5000-1500mm we can also produce un-standard size plate as customer required. the thickness is from 0.6-10.0 mm. we have about 5000 tons in stock. the produce date of us is very short.
Feather and Applications
the characteristics of 316L stainless steel
- cold rolling product outward appearance luster, beautiful;
- because of the added Mo, corrosion resistance, especially the pitting corrosion resistance good;
- high temperature strength outstanding; From "I want to stainless steel '
- good processing sclerosing (weak magnetic) after processing
- solid solution state non-magnetic;
- relative to 304 stainless steel, the price is higher.
application: pipe, heat exchanger, food industry, chemical industry, etc.
surface details and application
| Surface | Definition | Application |
| NO.1 |
The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. |
Chemical tank, pipe. |
| 2B |
Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. |
Medical equipment, Food industry, Construction material, Kitchen utensils. |
|
NO.3 |
Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. |
Kitchen utensils, Building construction |
|
NO.4 |
Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. |
Kitchen utensils, Building construction, Medical equipment. |
|
HL |
Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size |
Building Construction. |
|
BA (No.6) |
Those processed with bright heat treatment after cold rolling.
|
Kitchen utensils, Electric equipment, Building construction. |
Specifications
TISCO 1.5mm 4.0mm 8.0mm 316L stainless steel coil, grade 316L ss coils
size: 0.6-10.0mm x 1000mm -1500mm x C or as required
| Chemical Compostion |
C≤0.03 Si≤1.00 Mn≤2.00 P≤0.035 S≤0.03 Ni:12.0-15.0 Cr:16.0-18.0 Mo:2.0-3.0 |
| Mechanical properties |
Tensile strength (Mpa) 620 MIN The yield strength (Mpa) 310 MIN The elongation (%) for 30 MIN Covers an area of 40 MIN (%) |
Density(g/cm3) : 7.98
Our Capacity:
About us:strong technical force, complete product material specification
Specialize in :stainless steel pipe,stainless steel elbow,stainless steel pipe fitting
Main market:northern Europe, Western Europe, Mid East, Southeast Asia, South America
Management idea:do as good as our words, honesty, win-win, quality rooted, service supreme
