Duplex Stainless Steel Grade 2205 Astm A240 S31803 Plate DSS Plate S32205 DIN1.4462
Duplex stainless steel grades astm plate material s31803 for shipbuilding
Quick Detail
S31803 stainless steel sheet
|
Name |
S31803 stainless steel sheet |
Brand |
AUTO KUMPO/TISCO/BAOSTEEL |
|
size |
1219mm 1500mm 1800mm |
surface |
2B, BA, HL, 8K mirror, PVC coated |
|
thickness |
0.6-100mm |
Certificate |
SGS, BV |
duplex stainless steel sheet/plate S31803, 2205 duplex steel plate
Description
duplex stainless steel plate material S31803, duplex steel plate 2205
Details about our stainless steel sheet products:
| 1. Product: | Duplex stainless steel S31803 2205 sheet/plate/coil |
| 2. Thickness: | 0.1mm~100mm |
| 3. Width: | 10mm~1800mm |
| 4. Surface: | Shiny surface, 2B,NO.4 HL BA NO.8 8K , any color |
| 5. Standard: | ASTM A240 |
| 6 Finishing: | Cold rolled + annealed |
| 7. Materials: | 2205, S31803 (F51), S32205 (F60), 32750 (F53), S32760 (F55) |
| 8. Material origin: | TISCO, POSCO, LISCO, ZPSS, Bao steel, Krupp etc |
| 9. Application: | Gasket industry, pipe, power cable & oil well, shipbuilding, gas engineering. |
| 10. Coil ID: | 300MM, 400mm, 500mm as per customers’ request |
| 11. Coil weight: | as per client’s requirement. |
| 12. Delivery time | Be ready for shipment within 15~20 days upon receipt PO |
| 12. Package: | Plywood boxes. ( See pictures below ) |
| 13. Certificate: | ISO, BV, SGS, Mill test certificate |
Applications
- Pressure vessels, tanks, piping, and heat exchangers in the chemical processing industry
- Piping, tubing, and heat exchangers for the handling of gas and oil
- Effluent scrubbing systems
- Pulp and paper industry digesters, bleaching equipment, and stock-handling systems
- Rotors, fans, shafts, and press rolls requiring combined strength and corrosion resistance
- Cargo tanks for ships and trucks
- Food processing equipment
- Biofuels plants
Specifications
duplex stainless steel plate material S31803, duplex steel plate 2205
Chemical Compostion of commom duplex steel
|
type |
C |
Si |
Mn |
P |
S |
Cr |
Ni |
Mo |
N |
Cu |
W |
|
S31803 (F51) |
≤0.03 |
≤1.0 |
≤2.0 |
≤0.03 |
≤0.02 |
21.0~23.0 |
4.5~6.5 |
2.5~3.5 |
0.08~0.2 |
|
|
|
S32205 (F60) |
≤0.03 |
≤1.0 |
≤2.0 |
≤0.03 |
≤0.02 |
22.0~23.0 |
4.5~6.5 |
3.0~3.5 |
0.14~0.2 |
|
|
|
S32750 (F53) |
≤0.03 |
≤0.8 |
≤1.2 |
≤0.035 |
≤0.02 |
24.0~26.0 |
6.0~8.0 |
3.0~5.0 |
0.24~0.32 |
0.5 |
|
|
S32760 (F55) |
≤0.03 |
≤1.0 |
≤1.0 |
≤0.03 |
≤0.01 |
24.0~26.0 |
6.0~8.0 |
3.0~4.0 |
0.2~0.3 |
0.5~1.0 |
0.5~ |
Density(g/cm3) : 7.98
