DIN 1.4438 S31703 grade 317L Astm Stainless Steel Plate , Hot Rolled Polished SS Plate
DIN 1.4438 S31703 grade 317L Astm Stainless Steel Plate , Hot Rolled Polished SS Plate
Quick Detail
317L stainless steel plate
PRODUCTS | 317L stainless steel plate | Brand | TISCO BAOSTEEL |
| 1500x3000mm | | original: NO.1 |
thickness | 3.0-120mm | Certificate | SGS, BV |
grade 317L stainless steel plate
size: 1500 x 3000mm 1500 x 6000mm thickness: 3.0mm - 120mm
Brand: TISCO BAOSTEEL AUTO KUMPO
high quality and fast deliver
Description
About Our stainless steel plate
Width | 1000mm-2600mm |
Thickness | 0.3mm-100mm |
Length | As your requirements |
| 303se,304,TP304,TP304L,305,306,309S,310S,310H, TP316,TP316L,316Ti |
Minimum order | 1 Ton |
Standards | ASTM A511 A269 A312 A213, GB/ T14976-2002 GB 13296-91 |
FOB Price | the latest price |
Surface | polish, primary colour,matt,mirror face ,wire drawing |
Productions requirement | cold drawing, cold rolling, precision rolling |
Main markets | Asia,Europe,Middle-east area,Africa,South/North America |
Certification | ISO |
Application | chemical industry, metallurgy, construction, water conservancy |
Feather and Applications
317 l (00 cr19ni13mo3, UNS S31726) alloy is based on molybdenum austenitic stainless steel. It with conventional chrome - nickel austenitic stainless steel, such as, compared to 304 alloy has the stronger ability of resistance to chemical corrosion. In addition, compared with the conventional stainless steel, 317 l alloy has higher ductility, resistance to stress corrosion performance, compressive strength and resistance to high temperature performance. It is a low carbon level or L level, this level has during the welding and heat treatment process the sensitization effect of resistance.
Specifications
Relative 316 l, 317 l steel has excellent water resistance and resistance to SCC, used for Chemical ships, Chemical products, such as Reactor should be high corrosion-resistant Chemical equipment.
SUS317L mechanical properties
| YS (Mpa) | TS (Mpa) | EL (%) | HV |
| >=176 | >=480 | >=40 | <=200 |
SUS317L chemical composition
| C | Mn | Si | P | S | Cr | Ni | Mo |
| <=0.030 | <=2.00 | <=1.00 | <=0.045 | <=0.030 | <= 18.0 ~ 20.0 | <= 11.0 ~ 15.0 | <=3.0 ~ 4.0 |
Density(g/cm3) : 7.93
Our Advantages:
1 More than 200 patterns
2 Bottom price
3 Reliable quality and service
4 Fast delivery
Welcome to inquiry. Looking forward to cooperating with you in the near future.
