430 Brushed Stainless Steel Flat Bars, 1.4016 Cold Rolled SS Flat Bar 2B Finished
Quick Detail:
- 430 Stainless Steel Flat Bars, 1.4016 SS Flat Bars Cold Rolled SS Flat Bar 2B Finished
- grade: 201 301 304 304L 309S 310S 316 316L 317L 321 347 410 420 430 904L 2205 2507.etc
- size: 20x4 - 200x 40mm
- length: 6-8m or as required
- have stock
We can produce stainless steel flat bars as customer required
Description:
About our stainless steel flat bars
Manufacturers supply directly! | |
1) Product name: | Stainless Steel Flat Bar |
2) Stardard: | AISI,SUS,GB,JIS,ASTM,DIN etc. |
3) Grade: | 200,300,400series, 201,202,304,304L,309(S),310S,316,316L,410,430,etc. |
4) Size: | 3*20-10*100,3~30*12~100 Length:According to client's requirement |
5) Technology: | Bright Polished, Pickled ,Black,etc. |
6) Packing: | Export standard package, bundled or be required. |
7) Payment term: | T/T,L/C |
Deliver Time | produce deliver time: 10-15 days stock deliver time: 5-10 days |
Applications
Stainless steel flat steel can be according to the structure of the different needs of different kinds of stress components, also can make members between the joints. Widely used in various building structure and engineering structure, such as the beam, Bridges, transmission tower, lifting transportation machinery, ships, industrial furnace, reaction tower, container frame and warehouse shelves, etc.
Chemical Composition
| Material | Name | Elements | |||||||||
| C | Cr | Ni | Mn | P | S | Mo | Si | Cu | N | ||
| 201 | 1Cr17Mn6Ni5N | <0.15 | 16.0- 18.0 | 3.5-5.5 | 5.5-7.5 | <0.06 | <0.03 | ___ | <1.0 | ___ | <0.25 |
| 202 | 1Cr18Mn8Ni5N | <0.15 | 17.0-19.0 | 4.0-6.0 | 7.5-10.0 | <0.06 | <0.03 | ___ | <1.0 | ___ | <0.25 |
| 301 | 1Cr17Ni7 | <0.15 | 16.0-18.0 | 6.0-8.0 | <2.0 | <0.065 | <0.03 | ___ | <1.0 | ___ | ___ |
| 303 | Y1Cr17Ni7 | <0.15 | 17.0-19.0 | 8.0-10.0 | <2.0 | <0.20 | <0.03 | ___ | <1.0 | ___ | ___ |
304 | 0Cr18Ni9 | <0.07 | 17.0-19.0 | 8.0-10.0 | <2.0 | <0.035 | <0.03 | ___ | <1.0 | ___ | ___ |
| 304L | 00Cr19Ni10 | <0.03 | 18.0-20.0 | 8.0-10.0 | <2.0 | <0.035 | <0.03 | ___ | <1.0 | ___ | ___ |
| 309S | 0cr23Ni13 | <0.08 | 22.0-24.0 | 12.0-15.0 | <2.0 | <0.035 | <0.03 | ___ | <1.0 | ___ | ___ |
| 310S | 0Cr25Ni20 | <0.08 | 24.0-26.0 | 12.0-15.0 | <2.0 | <0.035 | <0.03 | ___ | <1.0 | ___ | ___ |
| 316 | 0Cr17Ni12Mo2 | <0.08 | 16.0-18.5 | 10.0-14.0 | <2.0 | <0.035 | <0.03 | 2.0-3.0 | <1.0 | ___ | ___ |
| 316L | 00Cr17Ni14Mo2 | <0.03 | 16.0-18.0 | 12.0-15.0 | <2.0 | <0.035 | <0.03 | 2.0-3.0 | <1.0 | ___ | ___ |
Competitive Advantage
- Good price
- good quality
- fast delivery time
We can also produce stainless steel angle bars, stainless steel rods, stainless steel bright bars, stainless steel hex bars, stainless steel channel bars, stainless steel square bars.etc
