304 stainless steel metal Sheets 0.6mm - 3.0mm with magnetic
304 stainless steel metal Sheets 0.6mm - 3.0mm with magnetic
Quick Detail:
Size: 1000x2000mm 1219x2438mm or as require
Thickness: 0.5 - 3.0mm
Tolerance: +-0-5%
Brand: TISCO BAOSTEEL.etc
|
Name |
317L stainless steel sheet |
Brand Name |
TISCO BAOSTEEL |
|
|
1219x2438mm |
|
2B BA NO.1 NO.4 HL 8K PVC |
|
thickness |
0.5-3.0mm |
Certificate |
SGS, BV |
Applications:
We,this material stainless steel plates be widely used in kinds of industries:
- Automobile, Household appliances, Petrochemical, Manufacture of machinery,
- Energy, Transportation, Metalwork, Aeronautics and Astronautics,
- Nuclear power and Electronic instruments.
Specifications
Designation: A240/A 240M-04a
Standard specifications For Chromium and Chromium-Nickel Stainless Steel Plate,Sheet, and Strip for Pressure Vessels and for General Applications
|
This specification covers |
Chromium and chromium-Nickel Stainless Steel Plate,Sheet, and Strip for Pressure Vessels and for General Applications |
|
Permitted Variations In Thickness for Cold-Rolled, Narrow, Coil-Processed Product as Coils and Cut Lengths
|
Thickness Tolerance,for the thickness and widths given.Over and Under,in. Width(w), in. w≤6, inc 6＜w≤12, inc 12＜w＜24, inc Specified Thickness,in. Thickness Tolerances 0.002 to 0.005,excl 10% 10% 10% 0.005to 0.010, incl 10% 10% 10% 0.005to 0.010, incl 0.0006 0.0008 0.001 Over 0.010 to 0.011, incl 0.0015 0.0015 0.0015 Over 0.010 to 0.012, incl 0.001 0.001 0.001 Over 0.011 to 0.013, incl 0.0015 0.0015 0.002 Over 0.013 to 0.017, incl 0.0015 0.002 0.002 Over 0.012 to 0.015, incl 0.001 0.0015 0.0015 Over 0.017 to 0.020, incl 0.0015 0.002 0.0025 Over 0.015 to 0.020, incl 0.001 0.0015 0.0015 Over 0.020 to 0.029, incl 0.002 0.0025 0.0025 Over 0.029 to 0.035, incl 0.002 0.002 0.002 Over 0.035 to 0.050, incl 0.0025 0.0035 0.0035 Over 0.050 to 0.069, incl 0.003 0.003 0.003 Over 0.069 to 0.100, incl 0.003 0.003 0.004 Over 0.100 to 0.125, incl 0.004 0.004 0.005 Over 0.125 to 0.161, incl 0.005 0.005 0.005 ........ ...... ...... |
Description:
TISCO Cold Rolled Inox 317L Sheets 0.6mm - 3.0mm Slit Edge
stainless steel sheet / stainless steel plate / stainless steel coils / stainless steel strip / stainless steel
317L stainless steel sheet / 317L stainless steel / stainless steel sheet / Inox 1.4438
|
Thickness |
0.5-3.0mm |
|
Width |
500-1500mm or as required |
|
Length |
1000mm-6000mm or customized |
|
Standard |
ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
|
Material Grade |
201 202 304 304L 321 316L 317L 347 409L 410 420 430 441 444 904L 2205 2507.etc |
|
Surface |
2B, BA, 8K, No. 4, HL ,etc. |
|
Brand name |
DB,TISCO, LISCO , ZPSS, BAOSTELL , etc. |
|
Packaging |
Standard export sea-worthy packing |
|
Technique |
Hot rolled stainless steel sheet and coil or Cold rolled stainless steel sheet and coil |
|
Delivery time |
7 working days |
|
Supply ability |
500 tons/ month |
|
Payment terms |
L/C, T/T ,etc. |
|
Remarks |
Thickness, width, length, standard and tolerance can be customized. |
About 317L material
- 317 l (00 cr19ni13mo3, UNS S31726) alloy is based on molybdenum austenitic stainless steel. It with conventional chrome - nickel austenitic stainless steel, such as, compared to 304 alloy has the stronger ability of resistance to chemical corrosion. In addition, compared with the conventional stainless steel, 317 l alloy has higher ductility, resistance to stress corrosion performance, compressive strength and resistance to high temperature performance. It is a low carbon level or L level, this level has during the welding and heat treatment process the sensitization effect of resistance.
- Relative 316 l, 317 l steel has excellent water resistance and resistance to SCC, used for Chemical ships, Chemical products, such as Reactor should be high corrosion-resistant Chemical equipment.
- SUS317L mechanical properties: YS (Mpa) 176 or higher, TS (Mpa) 480 or higher, EL (%) of 40 or higher, Hv 200 or less
- SUS317L chemical composition: carbon (C) 0.030 or less, manganese (Mn) of 2.00 or less, nickel (Ni) 11.0 ~ 15.0, silicon (Si) of 1.00 or less, phosphorus (P) of 0.045 or less, sulfur (S) of 0.030 or less, chromium (Cr) 18.0 ~ 20.0, molybdenum (Mo) 3.0 ~ 4.0
Competitive Advantage:
1, high quality
2, fast deliver
3, storage company and keeps about 8000 ton products in stock.
4, the best price.
5,have a stainless steel products process center and we can do all kind of stainless steel process treatment.
6, near Shanghai port, the traffice is very convenient.
