ASTM B622 ASME SB622 Stainless Steel Round Bar
ASTM B622 ASME SB622 Stainless Steel Round Bar Hastelloy C276 UNS N10276
Hastelloy C276 Price
1. fine after-sale services;
2. small order accepted;
3. samples available;
ASTM B575 Hastelloy C276 Nickel alloy strip is a tungsten-added nickel-molybdenum-chromium alloy designed to offer excellent corrosion resistance in wide range of severe environments. C-276 is widely used in the chemical field and petrifaction field, such as the element of chloride organic and catalyzes system. This Alloy is especially suit for high temperature environment, impure inorganic acid and organic acid (such as formic acid and acetic acid), sea-water corrosion environment.
Hastelloy C 276 Chemical composition
|
Grade |
% |
Ni |
Cr |
Mo |
Fe |
W |
Co |
C |
Mn |
Si |
V |
P |
S |
|
C-276 |
Min |
REM. |
14.5 |
15 |
4 |
3 |
|
|
|
|
|
|
|
|
Max |
16.5 |
17 |
7 |
4.5 |
2.5 |
0.01 |
1 |
0.08 |
0.35 |
0.04 |
0.03 |
Application:
- High temperature, inorganic acid and organic acid mixed with impurities (such as formic acid and acetic acid), sea water corrosion environment
- Pulp and paper industry, such as boiling solution and bleaching container
- washing tower in the FGD system, heater, wet steam fan, etc
- operation of equipment and components in the acidic gas environment
- reactor acetic acid and acid products
- sulfuric acid condenser
- methylene diphenyl isocyanate (MDI)
- impurity phosphoric acid production and processing
100% PMI;100% Hydrostatic Test or 100% NON-DESTRUCTIVE Test
Description & Name: ASTM B622 ASME SB622 Hastelloy C276 UNS N10276 Nickel alloy seamless tube/pipe
Standard: ASTM/ASME B/SB 622
Material: Hastelloy C276 ( UNS N10276 ), Hastelloy B-2 (UNS N10665),Inconel 600,625,617,690,693, Monel 400, Monel K500,Incoloy800/800H/800HT,825, Alloy20,Alloy28,AL6XN,N08028 etc.
Nominal Dia: 1/2 "to 10" NB for seamless pipe
Schedules: 5S, 10S, 40S, 80S, 10, 20, 30...120, 140, 160, XXS
All dimensions are in accordance with ANSI B36.19 and ANSI B36.10
Size Range for tubing: OD:1/4" (6.25mm) to 8" (203mm), WT 0.02" (0.5mm) to 0.5"(12mm)
Length:
30 m(Max) or as your requirement
Process:
Cold drawn, Cold rolled, Precision Rolled for Seamless Pipe or Tube
Finish: Annealed & pickled, bright annealing, polished
Ends: Beveled or plain end, square cut, burr free ,Plastic Cap at Both end
Packing: Bare packing/bundle packing with woven bag/wooden or steel frame crate packing/plastic cap protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested.
