2205 2507 Stainless Steel Metal Plate / Duplex S31803 S32205 S31803 Stainless Steel Plate
2205 2507 Stainless Steel Metal Plate / Duplex Stainless Steel Sheet
Product description
| Item | High quality super duplex stainless steel plate 2205, 2507 at factory price |
| Standard | ASTM A240,GB/T3280-2007,JIS4304-2005,ASTM A167,EN10088-2-2005,etc |
| Material |
310S,310,309,309S,316,316L,316Ti,317,317L,321,321H,347,347H,304,304L, 302,301,201,202,403,405,409,409L,410,410S,420,430,631,904L,Duplex,etc |
| Surface | 2B,2D,BA,NO.1,NO.4,NO.8,8K,mirror,checkered,embossed,hair line,sand blast,Brush,etching,etc |
| Thickness | 0.01~200mm |
| Width | 1000mm,1219mm,1500mm,1800mm,2000mm,2500mm,3000mm,3500mm,etc |
| Length | 2000mm,2440mm,3000mm,5800mm,6000mm,etc |
| Package | Standard export package,suit for all kinds of transport,or as required. |
|
Container Size |
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High) |
| Price term | Ex-Work,FOB,CNF,CFR,CIF,FCA,DDP,DDU,etc |
| Payment term | TT,L/C,western Union |
| Export to |
Ireland,Singapore,Indonesia,Ukraine,Saudi Arabia,Spain,Canada,USA,Brazil,Thailand,Korea,Iran, India,Egypt,Oman,Malaysia,Bangladesh,Dubai,Viet Nam,Kuwait,Peru,Mexico,Russia,etc |
| MOQ | 500Kg |
| Application |
Stainless steel plate applies to construction field, ships building industry, petroleum,chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and hardware fields.Stainless steel plate can be made according to the customers requirements. |
| Contact |
If you have any question,please feel free to contact me . we are sure your inquiry or requirements will get prompt attention |
main stainless steel products:
stainless steel plate/coil; stainless steel pipe; stainles steel bar,etc.
other prodcuts include carbon steel, alloy steel,galvanzied steel--plate/coil/pipe/bar,etc
structural steel: flat bar, H beam, angle bar,C beam,I beam,
1.we are powerful manufacturer audited by world top inspection company SGS,BV ,ISO and TUV.
2. our products have been exported to more than 70 countries and regions.our quality and fame can be assured.
3.We offered the best price based on best quality.
4.we own the most modern equipment and production line.
Our Goal:supply quality products with the best services and satisfy the
requirements of clients from at home and abroad;
Management philosophy:Pursue the best quality, the best price, the best service and the best credit standing
Corporation culture:Innovation is an eternal motif; surpass excellence is our
unremitting pursuit.
| Chemical Properties: | |||||||||
| C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 2205 | 0.03 | 2 | 1 | 0.03 | 0.02 | min: 21.0 | min: 2.5 | min: 4.5 | min: 0.08 |
| (S31803) | max | max | max | max | max | max: 23.0 | max: 3.5 | max: 6.5 | max: 0.20 |
| 2205 | 0.03 | 2 | 1 | 0.03 | 0.02 | min: 22.0 | min: 3.0 | min: 4.5 | min: 0.14 |
| (S32205) | max | max | max | max | max | max: 23.0 | max: 3.5 | max: 6.5 | max: 0.20 |
| Mechanical Properties: | |||||
| Grade | Tensile Strength | Yield Strength | Elongation % | Hardness (HB) MAX | |
| ksi (min) | 0.2% ksi (min) | ||||
| 2205 | 90 | 65 | 25 | 217 | |
Corrosion Resistance:
-
Due to its high chromium, molybdenum, and nitrogen content, Duplex 2205 demonstrates superior corrosion resistant properties to 316 and 316L in most environments
-
Chromium, molybdenum, and nitrogen content also provide high resistance to pitting and crevice corrosion, even in oxidizing and acidic solutions
-
Resistant to chloride stress corrosion cracking and temperatures of up to about 302°F (150°C)
-
The presence of ferrite provides for good performance of Duplex 2205 in caustic environments
Heat Resistance:
-
Similar to other duplex stainless steels, Duplex 2205 has good oxidation resistance at high temperatures
-
Subject to embrittlement when exposed to temperatures above 572°F (300°C) even when exposed for short periods of time; Duplex 2205 is therefore not recommended for use above 572°F (300°C)
