Cold Rolled Nickel Alloy Hastelloy C / C22 / C4 / C276 Plate / Hastelloy Plate
Price:
20-35 USD/KG
MOQ:
1 tons
Delivery Time:
7 DAYS
Brand:
MITTEL
Product Description
Nickel alloy hastelloy C / C22 / C4 / C276 plate / sheet price
Product Description
Chemical composition
| Alloy | % | Ni | Cr | Mo | Fe | W | Co | C | Mn | Si | V | P | S |
| C | Min | Rest | 14.5 | 15 | 4 | 3 | |||||||
| Max | 16.5 | 17 | 7 | 4.5 | 2.5 | 0.08 | 1 | 1 | 0.35 | 0.04 | 0.03 | ||
| C22 | Min | Rest | 14.5 | 15 | 4 | 3 | |||||||
| Max | 16.5 | 17 | 7 | 4.5 | 2.5 | 0.01 | 1 | 0.08 | 0.35 | 0.04 | 0.03 |
Hastelloy C Physical properties:
| Density | 8.9 g/cm³ |
| Melting point | 1325-1370 ℃ |
Hastelloy C alloy minimum mechanical properties in the room temperature
| Alloy state | Tensile strength Rm N/mm² |
Yield strength R P0. 2 N/mm²
|
Elongation A 5 % |
| C /C22 | 690 | 283 | 40 |
What are the characteristics of Hastelloy C/C22?
- Excellent corrosion resistance in reducing environments
- Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
- High nickel and molybdenum contents providing good corrosion resistance in reducing environments
- Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected zones of welded joints
- Resistance to localized corrosion such as pitting and stress-corrosion cracking
- One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide
In what applications is Hastelloy C/C22 used?
- Pollution control stack liners, ducts, dampers, scrubbers, stack-gas reheaters, fans and fan housings
- Flue gas desulfurization systems
- Chemical processing components like heat exchangers, reaction vessels, evaporators, and transfer piping
- Sour gas wells
- Pulp and paper production
- Waste treatment
- Pharmaceutical and food processing equipment
In what forms is Hastelloy C/C22 Available?
- Sheet
- Plate
- Pipe & Tube (welded and seamless)
- Wire
- Fittings
- bar
