ASTM A544 201 Stainless Steel Welded Pipe Mirror Polished 180 grits 38*1.5*6000mm
| Material |
304:0cr18ni9, 0cr17ni8 201:1cr17mn6ni5n,1cr13mn9ni1n 316:0cr17ni12 or as customer’s request |
| Size(round pipe) |
9.5, 12.7, 15.9, 17, 18, 19.1, 20, 21, 22.2, 23, 25.4, 28, 318, 35, 60, 63.5, 73, 76.2, 88.9, 101.6, 114.3, 127, 133, 159, 168, 219 mm or customized |
| Size (square pipe) |
10×10,12×12,18×18,23×23,38×38,50×50,70×70,100×100,20×10,23×10,24×12,25×13,36×23, 40×20,50×20,60×15,75×45,80×60,95×45,100×60,150×100 mm or customized |
| Size (oval pipe) | 30×15,80×40 mm os customized |
| Thickness | 0.24-3 mm |
| Length | 6m or according to customer’s request |
| Outer diameter | 6.35-219mm |
| Tolerance | Outer diameter :±0.2mm |
| Thickness :±0.02mm | |
| Length :±0.5mm | |
| Process method | Code drawn, annealed with nitrogen protection, ultrasonic,automatic shape, polished |
| Finishing |
A: sanded B: 400#-600# mirror C: hairline brushed D: TIN titanlum E : HL brushed & mirror (two kinds of finishing for one pipe) |
| Chemical Composition | |||||||
| Material | C | Si | Mn | P | S | Cr | Ni |
| 201 | ≤0.12 | ≤0.75 | 9.5-12.5 | ≤0.045 | ≤0.03 | 13-16 | 0.8-1.5 |
| 304 | ≤0.08 | ≤0.75 | ≤2.0 | ≤0.045 | ≤0.03 | 18-19 | 8-10 |
| 316 | ≤0.08 | ≤1.00 | ≤2.0 | ≤0.035 | ≤0.03 | 10-14 | 16.0-18.5 |
| 430 | ≤0.12 | ≤0.75 | ≤2.0 | ≤0.04 | ≤0.03 | 16-18 |
≤0.6
|
ASTM A544 201 Stainless Steel Tube Mirror Polished Outside and Inside 180 grits 38*1.5*6000mm
201 Stainless steel pipe
1) Process method: Cold drawn/cold rolling
2) Surface finish: Annealed / cold pilgered / manual polished / mechanical polished
3) Standards:
A) GB/T 14975-2002, GB/T 14976-2002, GB 13296-91
B) ASTM A213, ASTM A312, ASTM A269, JIS G3459, JIS G3463, JIS G3448, DIN17458
4) Steel grade: 201.202.301.304.304L. 310S. 316.316L. 321.347H. 430 and etc.
5) Outside diameter: 6mm - 630mm
6) Wall thickness: 0.5mm - 30mm
7) Length: 1m - 12m
8) Application range: For foodstuff, medical equipment, boilogy, electron, chemical, petroleum, fertilizer, boiler, nuclear energy, and etc.
9) Packing: In seaworthy wooden cases or in bundles
10) MOQ: 1 ton
11) Terms of payment: 30%T/T in advance, the balance against B/L copy or L/C at sight
12) Delivery: 25 days after confirming the order or negotiation
ISO&SGS&BV Audited company
Advanced production line and inspection equipment
Finished Product Inventory: More Than 800 Tons.
Prompt delivery from stock.
Convenient transportation
We can offer competitive price with best quality&service
More than 10 years export experience
More than 20 years industry experience
More than 30 countries worldwide customers
If you are interested in our products or any thing I can do for you, please feel free to contact me any time.
Contact sales person: Rachel Cheng +86 138 205 97807 / 86 22 86896631 ext 609
| Standard Name | Chemical Composition | Mechanical Properties | ||||||||||||||
| JIS | GB | AIST | EN | C | Si | Mn | P | S | Ni | Cr | Others | Yield Strength | Tensile | Elongation | Hardness | |
| UNS | max | max | max | max | max | max | N/mm2 | N/mm2 | % | HV | HRB | |||||
| Austenitic stainless steels | ||||||||||||||||
| SUS201 | 1Cr17Mn6Ni5N | 201 | ** | 0.15 | 1 | 5.50- 7.50 |
0.06 | 0.03 | 1 | 16.00- 18.00 |
N0.25 | 245 | 640 | 40 | 253 | 100 |
| SUS202 | 1Cr18Mn8Ni5N | 202 | ** | 0.15 | 1 | 7.50- 10.00 |
0.06 | 0.03 | 4.00- 6.00 |
17.00- 19.00 |
N0.25 | 245 | 590 | 40 | ||
