20CrMnTiH Steel Round Rod ASTM SAE5120 DIN1.7147 Forged Steel Bar Quenching and Temperature
20CrMnTiH Steel Round Rod ASTM SAE5120 DIN1.7147 Forged Steel Bar Quenching and Temperature
20CrMnTi| GB/T 3077 20CrMnTi Alloy Steel Plate
Specification in 20CrMnTi
Thickness: 8MM to 250 MM,
Width: 1500mm to 4050mm,
Length: 3000mm to 15000mm
Mittel is specialized in supplying Alloy steel plate in 20CrMnTi. For more information of 20CrMnTi steel plates, please check them in following:
| 20CrMnTi Chemical Composition | |||||
| Grade | The Element Max (%) | ||||
| C | Si | Mn | P | S | |
| 20CrMnTi | 0.17~0.23 | 0.17~0.37 | 0.80~1.10 | 0.035 | 0.035 |
| Grade | 20CrMnTi Mechanical Property | |||
| Thickness | Yield | Tensile | HB | |
| 20CrMnTi | mm | Min Mpa | Mpa | HB |
| 6-50 | 850 | 1080 | ||
| 50-200 | 850 | 1080 | ||
For more information about GB/T 3077 Alloy steel plate, please clicking Mill Technical Information
If GB/T 3077 20CrMnTi covers the following issues of hot rolled and forging alloy steel: the dimension, shape, weight, tolerance, engineering specification, test method, inspection rules, packaging, marking, and quality certificates.
The standard applies to alloy structural steel bar 250mm maximum diameter or thickness. After consultation between the two sides of supply and demand, bar stock of diameter greater than 250 mm can also be provided
The chemical compositions of steel grades specified in the standard also apply to steel ingot, billet and its productions.
20CrMnTi Alloy Steel Bar
1. Features Specifications: 20CrMnTi Alloy Steel Bar
2. Commodity:20CrMnTi Alloy Steel Bar
3. Hot rolling craftwork and fine mechanical performance
4. Chemical components meet standards, delivery in black skin
5. Standards: GB/T3077 20CrMnTi
6. Size: dia 18 - 460 mm
7. Length:6M above
8. Packing:Bundles
Chemical Composition:
| C | Si | Mn | Cr | S | P | Ni | Cu | Ti |
| 0.17~0.23 | 0.17~0.37 | 0.80~1.10 | 1.00~1.30 | ≤0.035 | ≤0.035 | ≤0.030 | ≤0.030 | 0.04~0.10 |
Our company can supply various kinds of steel bars.Welcome to send us inquires!
A: Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case.
2.Q: Can provide OEM/ODM service?
A: Yes. Please feel free to contact us for more details discuss.
3.Q: What product information do I need to provide?
A:One is 30% deposit by TT before production and 70% balance against copy of B/L; the other is Irrevocable L/C 100% at sight.
4.Q: Can you provide sample?
A: The sample could can provide for customer with free, but the freight will be covered by customer account. The sample freight will be returned to customer account after we cooperate.
5.Q: How to pack the products?
A: The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can effectively protect products from corrosion during ocean transportation.
6.Q: What's the MOQ ?
A: We welcome your trial order MOQ 25Tons to be stuffed in 1*20GP. Large quantity can reduce your cost.
7.Q: What's your delivery time ?
A:Regular lead time is 7-10 days after received deposit.
8.Q: What's your market ?
A:South American/Africa/Middle East/Europe/Korea/Russian Federation ETC.
