GI Hot - Dipped Galvanized Steel Coils High Strength Steel Plate , Thickness 0.3mm - 10mm
High-strength Steel Plate Special Use and Galvanized Surface Treatment GI Hot-Dipped Galvanized Steel Sheet and Coil
Creating Galvanized Steel Coils
As a leading galvanized steel coil manufacturer, Jiangsu Mittel Steel employs best industry practices in the creation of our products. Our loyal customers can rest assured that Sinowell Metal features exacting processes to produce our hot dipped galvanized steel coils. During the production process, our engineers place cold rolled steel coils through our uncoiler. The steel travels through an accumulator where it undergoes pretreatment.
Specifications:
| Thickness | 0.3mm - 10 mm |
| Width | 1000mm, 1219mm, 1250mm or as your requirements |
| Inner diameter | 200 / 325 / 400 / 508 / 610 mm |
| Outer diameter | 2000 mm Max |
Technical Specifications:
| Designation Type | KS D 3506 | JIS G 3302 | ASTM | EN | |||
| cold- rolled base metal used | hot- rolled base metal used | cold- rolled base metal used | hot- rolled base metal used | OLD | A653-97 |
||
| Surface finish | |
| Type | Surface Finish |
| Regular | Standard spangles with flower pattern, suited for general use |
| Zero | More minimized spangles than regular, with a beautiful gloss, suited for general painting applications |
| Ultra | Extremely minimized spangles suited for special painting applications |
| Alloy coated iron-zinc | Galvannealed steel sheet has a highly workable iron-zinc alloy layer. Good paint-adherence properties, corrosion resistance and weldability make them ideal for use in home electrical appliances and buildings |
| Surface Treatment | |
| Type | Application |
| Chromate | General |
| Non-treated | General painting |
| Organic | Drawing |
In order to guarantee its quality, this steel coil and sheet is severely tested on varied standards. We offer this steel coil and sheets in a range of specifications as per the demands of customers.
Features:
- High strength
- Elevated durability
- Hardness & ductility
- Compact design
Atmospheric Corrosion Resistance:
- Based on many year atmospheric corrosion R&D tests, it is estimated that 55% Al-Zn sheet will outlast G90 galvanized by two to four times in marine, industrial and rural atmospheres. 55% Al-Zn panels are still rust-free after 30 years in all but the severe marine environment. The estimated life of the 55% Al-Zn coating (years to first rust) based on these 30-years tests ranges from 14 years to 40 or more years.Thickness range is 0.2mm to 0.95mm.
We guarantee our products meet stated criteria and grades that include primary standards such as:
ASTM A653M
This is the American standard for cold rolled materials.
JIS G 3302
This is the Japanese material standard associated with hot dipped galvanized steel coils.
Sinowell Metal produces hot dipped galvanized steel coils in the following grades:
DX51D+Z (St01Z, St02Z)
CSA, CSB, CSC
SGCC
DX52D+Z (St03Z), DX53D+Z (St04Z, St05Z), DX54D, DX56D, DX57D
DDSA, DDSC
SGCD1, SGCD2, SGCD3
S220GD+Z (StE220Z), S250GD+Z (StE250Z), S280GD+Z (StE280), S320GD, S350GD
SS33(SS230), SS37(SS255), SS40(SS275)
SGC340, SGC400
S320GD+Z (StE320Z), S350GD+Z (StE350Z), S350GD+Z, S390GD+Z, S450GD+Z
SS50(SS340), SS55(SS380), SS80(SS550)
SGC440, SGC490
