ASTM A312 TP 310S Stainless Steel Seamless Tube DIN 1.4845 Inox Pipe
ASTM A312 TP 310S Stainless Steel Seamless Tube DIN 1.4845 Inox Pipe
1. Product Details:
1) Commodity name: Stainless steel seamless pipe / Stainless Steel Seamless Tube
2) Steel grades: TP310S / AISI 310S / SS 310S/ S31008
3) Standard: ASTM A312, ASTM A213, ASTM A269, ASTM A511 ,ASTM A249, ASTM A270,
4) Size: Out diameter: ANSI 1/8’’-24’’ (6mm-920mm).
Wall thickness: ANSI 5S-XXS (0.6mm-60mm)
Length: Max.18 meters
5) Tolerance: According to the Standard.
6) Process methods: cold dawning / cold rolling
7) Surface condition: annealed and pickled with natural color, or polished 180G,
320G, 400G Satin / Hairline as customer’s instruction.
8) Delivery conditions: Solution annealed, pickled, grey white
9) End Type: Plain ends / Bevel edges ends
2. Payment & Shipping Terms:
1) Minimum Order Quantity: 0.5-1 tons
2) Price: Negotiable
3) Packaging : In seaworthy wooden cases or in bundles as customer’s request.
4) Delivery Time: According to the quantity.
5) Payment Term: T.T.
6) Supply Ability: 1000tons per month
7) Certificates: ISO9001:2000 quality system.BV, TUV, LLOYDS, DNV, SGS, etc. the third party inspection is available
8) Test: UT, ET, HT, RT,ect, and others according to the standard,
or as the requests of the customer
9) What documents we supply: Invoice,Packing List,Mill Test Report,Original Certificate,Bill of Lading.
3.Specifications:
ASTM A312 Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes
ASTM A790 Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe
ASME SA213 Seamless Ferrite and Austenitic Alloy Steel Pipe for Boiler, Superheater and Heat Exchanger
ASTM A511 Standard for Mechanical Stainless Steel Tubing
ASTM A554 Specification for Welded Stainless Steel Mechanical Tubing
ASME SA249 Standard Specification for Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser Tubes
ASME SA789 Standard Specification for Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser Tubes
ASTM A269 Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
ASTM A268 Standard Specification for Seamless and Welded Ferritic and Martensitic Stainless Steel Tubing for General Service
ASTM A270 Standard Specification for Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing
We are manufacturer of 310 stainless steel pipes and supply high quality 310 stainless steel pipes in both large and small quantities worldwide &
offer you the best prices in the market.
We have a team of experienced professionals with years of experience in manufacturing.
310 Stainless Steel Pipes & Tubes Specification
Himesh Steel supplies welded austenitic, duplex and nickel alloy welded stainless steel pipes in accordance with:
- ASTM A312
- ASTM A358 Class 1, 2, 3, 4, 5
- ASTM A790
- ASTM A928 Class 1, 2, 3, 4, 5
- API5LC
- ASTM B775
- EN10217-7 TC 1/2
- Customer specification
CHEMICAL COMPOSITION
The chemical composition of 310 Stainless Steel is provided in the table below.
|
Chemical Composition
|
Type 310
|
|
Carbon
|
0.25 max
|
|
Manganese
|
2.00 max
|
|
Silicon
|
1.50 max
|
|
Phosphorus
|
0.045 max
|
|
Sulphur
|
0.030 max
|
|
Chromium
|
24.00 – 26.00
|
|
Nickel
|
19.00 – 22.00
|
MECHANICAL PROPERTIES
The mechanical properties of 310 Stainless Steel are provided in the table below.
|
Mechanical Properties
|
Type 310
|
|
Grade 0.2 % Proof Stress MPa (min)
|
205
|
|
Tensile Strength MPa (min)
|
520
|
|
Elongation % (min)
|
40
|
|
Hardness (HV) (max)
|
225
|
PHYSICAL PROPERTIES
|
Properties
|
at
|
Value
|
Unit
|
|
Density
|
8,000
|
Kg/m3
|
|
|
Electrical Conductivity
|
25°C
|
1.25
|
%IACS
|
|
Electrical Resistivity
|
25°C
|
0.78
|
Micro ohm.m
|
|
Modulus of Elasticity
|
20°C
|
200
|
GPa
|
|
Shear Modulus
|
20°C
|
77
|
GPa
|
|
Poisson’s Ratio
|
20°C
|
0.30
|
|
|
Melting Rnage
|
1400-1450
|
°C
|
|
|
Specific Heat
|
500
|
J/kg.°C
|
|
|
Relative Magnetic Permeability
|
1.02
|
||
|
Thermal Conductivity
|
100°C
|
14.2
|
W/m.°C
|
|
Coefficient of Expansion
|
0-100°C
|
15.9
|
/°C
|
| No. | Material | Size | Sch. & Swg. | Specification |
| 1. | Seamless Pipe | 15 mm NB
To 300 mm NB |
Sch. 5s, 10s, 40s, 80s, 160s, XXS | ASTM A-312 |
| 2. | Welded (ERW) Pipe | 15 mm NB
To 300 mm NB |
Sch. 5s, 10,
40s & 80s |
ASTM A-312 |
| 3. | Welded (ERW) Pipe | 150 mm NB
To 600 mm NB |
Sch. 5s, 10s,
40s & 80s |
ASTM A-358 |
| 4. | Seamless Tube | 6.35 mm OD To
101.6 mm OD |
20 Swg., 18 Swg.,
16 Swg., 14 Swg., 12 Swg., 10 Swg. |
ASTM A-213 |
| 5. | Welded (ERW) Tube | 6.35 mm OD To
152 mm OD |
20 Swg., 18 Swg.,
16 Swg., 14 Swg., 12 Swg., 10 Swg. |
