1.4509 AISI 441 Stainless Steel Data Sheet SUS441 Stainless Steel Panels 1.0*1220*2440MM
441 Stainless Steel Sheet, SS 441 Sheets, Stainless Steel 441 Sheets Supplier in China , ASTM A240 TP 441 Sheets, SS 441 Sheet Stockist in WU XI , China
Type 441 is chromium and dual stabilized ferritic stainless steel that is similar to 304-grade stainless steel. This grade of sheets is widely used for high-temperature services and used in annealed and cold formed condition applications. It even has good weldability due to the niobium and titanium stabilization. Furthermore it has excellent resistance to corrosion. Panchdeep metal is the leading manufacturers of AISI/SS 441 Sheet, manufactured using top-notch quality of raw material and latest machines.
ASME SA240 Grade 441 Sheets, 441 SS Sheets Exporter, SS 441 HR Sheets, 441 Stainless Steel CR Sheets, SS Gr. 441 Sheets Dealer in India, Austenitic Stainless Steel 441 Sheet, AISI 441 Sheets.
We manufacture and designed these sheets in accordance with global and domestic standards. These sheets are extremely durable and long lasting and can be accessed in different shapes and sizes. Worldwide customers purchase this grade of sheets in different shapes and types due to their excellent features and properties.
The features of stainless steel sheets include:
- Moderate formability
- Improved creep resistance
- Higher oxidation resistance
- Excellent corrosion resistance
- High tensile strength
- Durability
- Workability
These sheets are made using top-notch quality of raw material as well as the latest technology used to create the accurate size and length of these sheets. In addition to it, there are several tests and inspections done which includes:
- Flattening test
- Flaring test
- Third party inspection
- Radiography test
- Ultrasonic test
For all these tests, different test certificates are approved that are offered to customers proving sheets quality. In the end, the AISI/SS 441 Sheet is packed with labeling in the high quality of packaging material and delivered to their respective customers worldwide.
Stainless Steel 441 Sheets Specifications:
| Specifications | ASTM A240, ASME SA240 |
| Dimensions | ASTM, ASME and API |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Surface | 2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,etc. |
| Finish | Black,Bright Polished,Rough Turned,No.4 Finish,Matt Finish,BA Finish |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc. |
Grade Specifications for Stainless Steel 441 Sheets
Chemical Properties of SS 441 Sheets
| Gr | C | Mn | P | S | Si | Cr | Ni | N | Ti | Nb |
| SS 441 | 0.03 max. | 1.00 max. | 0.04 max. | 0.03 max. | 1.00 max. | 17.5 -19.5 | 1.00 max. | 0.03 max. | 0.10 – 0.50 | 0.30 + 9xC min., 0.90 max. |
Mechanical Properties of SS 441 Sheets
| UTS Ksi.(Mpa) | 0.2% Yield Strength Ksi.(Mpa) | Elongation % in 2″ (50.8 mm) | Rockwell Hardness |
| 71 (490) | 45 (310) | 32 | B78 |
