Nitronic 60 (S21800 /AMS 5848)
Technical Data Sheet
| Chemical Composition Limits | |||||||
| Weight% | Ni | Cr | Mn | Si | N | Mo | C |
| Nitronic 60 | 8-9 | 16-18 | 7-9 | 3.5-4.5 | 0.08-0.180 | 0.75 max | 0.10 max |
Nitronic 60 is a high Silicon, high Manganese, Nitrogen strengthened austenitic stainless alloy. Nitronic 60 is an all purpose metal that was originally designed as a temperature alloy and therefore performs well at high temperature around 1800ºF. The additions of silicon and manganese assist to inhibit wear, galling and fretting even in the annealed condition. Through cold working Nitronic 60, it is possible to attain higher strengths, however it does not enhance the anti-galling properties. The oxidation resistance of Nitronic 60 is similar to Alloy 309 and far superior to Alloy 304.
Nitronic 60 is used in the Aerospace , Food and Drug, Oil Field, Petrochemical, Surgical and Chemical Processing Industries.
Typical Mechanical Properties
| Alloy | Condition | Ultimate Tensile Strength (ksi) | Yield Strength (0.2%) ksi | Elongation in 4D (%) | Reduction of Area % | Hardness HB |
| Nitronic 60 | Solution Treated (AMS 5848) <0.5" |
105 | 55 | 35 | 55 | 170-255 |
| Nitronic 60 | Solution Treated (AMS 5848) >0.5" |
95 | 50 | 35 | 55 | 170-255 |
Availability
Nitronic 60 is available in Sheet, Plate, Strip, Bars (Round, Square), Wire, Forgings, Rings, Extrusions and Welding Wire. For all stock availability contact Sales.
Nitronic 60 is also available strain-hardened for increased strength and hardness. Different levels of strength can be achieved as in the following table:
| Alloy | Strength Level | Diameter Range | Ultimate Tensile Strength ksi (min) | Yield Strength ksi (min) | Elongation (min) | Reduction of Area (min) |
| Nitronic 60 HS | 1 | 0.125" - 4.00" | 110 | 90 | 35 | 55 |
| Nitronic 60 HS | 2 | 0.125" - 4.00" | 135 | 105 | 20 | 50 |
| Nitronic 60 HS | 3 | 0.125" - 3.50" | 160 | 130 | 15 | 45 |
| Nitronic 60 HS | 4 | 0.062" - 2.00" | 180 | 145 | 12 | 45 |
| Nitronic 60 HS | 5 | 0.062" - 1.50" | 200 | 180 | 10 | 45 |
Specifications
AMS 5848 Bar / Forgings/ Wire - Nitronic 60 Bars, Wire and Forgings
ASTM A240 - Nitronic 60 sheet and plate
ASTM A193 Grade B8S
ASTM A194 / ASME SA194
ASTM A276 / ASME SA276
ASTM A479 / ASME A479
ASME SA194
ASME SA479 Grade B8S
UNS S21800
