Gcr15 Steel Round Bar SAE52100 Bearing Steel Bar EN 100Cr6 DIN 1.2067

Price Negotiable
Price: 1.5 USD/KG
MOQ: 100KGS
Delivery Time: 14 days
Brand: MITTEL
Product Description

Gcr15 Steel Round Bar SAE52100 Bearing Steel Bar EN 100Cr6 DIN 1.2067



GB/T 18254 GCr15 stainless steel belongs to bearing stell. Among various bearing steel, GCr15 has high cost performance. So GB/T 18254 GCr15 is widely used in the industrial field.

GB/T 18254 GCr15 stainless steel can be produced into hot rolled round bars and square bars, cold-drawing bars,forged bars. We henan bebon can supply GB/T 18254 GCr15 all of shapes.

Based on GB/T 18254 GCr15 stainless steel properties, GCr15 stainless steel round bars are mainly used to manufacture shaft of internal-combustion engine,electromobile, machine tool,tractor,steel rolling machines,sounding borer,railway vehicles and mining machine.

According to the market needs, henan bebon supply the oversea markets for GB/T 18254 GCr15 hot rolled round bars OD 6mm -80 mm and GCr15 forged round bars OD 80 mm - 1200 mm, also GB/T 18254 GCr15 forged square bars OD 100- 1200 mm. The OD tolerance is about 0-3 mm and length tolerance is about 0-20 mm.

GB/T 18254 GCr15 round bars are usually produced under the followed procedures: EAF arc furnace + LF purify affinage + VDF + ingot steel(bottom gating /argon) + forged + annealing + black polishing (turnery) + GB/T6402-92 ΙΙ UT test + smooth edges with sawing .

GB/T 18254 GCr15 round bars chemical composition by %,maximum

Grade C Si Mn Cr P S Mo Ni Cu
GB/T 18254 GCr15 0.95-1.05 0.15-0.35 0.25-0.45 1.4-1.65 ≤0.025 ≤0.025 ≤0.1 ≤0.3 ≤0.25

GB/T 18254 GCr15 round bars mechanical properties

Grade Delivery State

Hardness,

(annealing or tempering) HBW,max

Forging ratio

Grain Size

(level)

Nonmetal ratio
GB/T 18254 GCr15

Hot rolled,forged,hot rolled (forged) balling annealing,

hot rolled intenerating annealing, hot rolled intenerating

annealing decorticating

179-207 ≥ 4:1 ≥ 6 ≤ 2.0

If you need GB/T 18254 GCr15 round bars, or other grades,pls be free to contact us.
