UNS N06022 Hastelloy C22 Plate Machinability Astm Nickel Base Alloy Grade
Price:
45 USD/KG
MOQ:
50KGS
Delivery Time:
7 Working Days
Brand:
MITTEL
Product Description
Hastelloy C22 Plate UNS N06022 Plate Hastelloy C22 Machinability Hastelloy C22 Astm
Standard specifications for ASTM B626 Hastelloy C22 Plate. If any specification is not mentioned here, you can contact us. We also manufacture and export any custom specification as per clients requirement.
| Specifications | ASTM B626, ASME SB626 |
| Dimensions | ASTM, ASME and API |
| Size | Thickness 0.5-100mm |
| Specialized in | Large Diameter Size |
| Range | Width 1000-2500mm |
| Type | plate |
| Form | plate |
| Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Threaded |
Hastelloy C22 ASTM B626 plate Chemical Composition
| Grade | ASTM B626 Hastelloy C22 | |
|---|---|---|
| min | max | |
| C | – | 0.010 |
| Mn | – | 0.50 |
| Si | – | 0.08 |
| P | – | 0.02 |
| S | – | 0.02 |
| Mo | 12.5 | 14.5 |
| Ni | Balance | Balance |
| Cr | 20.0 | 22.5 |
| Fe | 2.0 | 6.0 |
| Co | – | 2.5 |
| V | – | 0.35 |
| W | 2.5 | 3.5 |
ASTM B626 Hastelloy C22 plate Mechanical Properties
| Grade | ASTM B626 Hastelloy C22 | |
|---|---|---|
| Tensile Strength (MPa) min | Psi – 100000 , MPa – 690 | |
| Yield Strength 0.2% Proof (MPa) min | Psi – 45000 , MPa – 310 | |
| Elongation (% in 50mm) min | 45% | |
Hastelloy C22 Welded Tube Physical Properties
| Grade | ASTM B626 Hastelloy C22 | |
|---|---|---|
| Density | 8.69 g/cm3 | |
| Melting Point | 1399 °C (2550 °F) | |
Hastelloy ASTM B626 C22 plate Equivalent Grades
| Grade | ASTM B626 Hastelloy C22 | |
| UNS No | N06022 | |
| Old British | BS | – |
| En | NiCr21Mo14W | |
| Euronorm | No | 2.4602 |
| Name | – | |
| AFNOR | – | |
| Japanese JIS | NW 6022 | |
| GOST | – | |
Our pipes and tubes are used in a wide range of applications and various industries. Below are a few of them:
- Gas Processing Industries
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Chemical Industries
- Oil & Gas Industries
- Fertilizers Industries
- Sugar Industries
ASTM B626 Hastelloy C22 plate Stock Availability
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for ASTM B626 Hastelloy C22 plate
