SUS301 Stainless Steel Strip 2mm Full Hard HV590 301 Stainless Steel Data Sheet
Price:
3.48 USD/KG
MOQ:
200KGS
Delivery Time:
14 Days After Received the Payments
Brand:
TISCO ZPSS
Product Description
SUS301 Stainless Steel Strip 2mm Full Hard HV590 301 Stainless Steel Data Sheet
General Properties
Stainless steel grade 301 is a commonly available austenitic stainless with good corrosion resistance and elevated carbon to allow for cold working to a variety of tempers. It can be obtained in the 1/4 hard, 1/2 hard, and full hard.
Specifications: S30100
Applications:
High strength and excellent corrosion resistance make Type 301 Stainless Steel useful for a wide variety of applications. Typical uses include:
- aircraft structural parts
- trailer bodies
- utensils
- architectural and automotive rim
- roof drainage products
- conveyor belts
- variety of industrial applications.
Standards:
- ASTM/ASME: UNS S30200
- EURONORM: X 12 CrNi 17 7
- DIN: 1.4310
Corrosion Resistance
- Good resistance in applications involving external exposure to mildly corrosive conditions at ambient temperatures.
- Resists outdoor, industrial, marine, and mild chemical environments
- susceptible to carbide precipitation during welding, which restricts its use in some applications
- Similar to resistance of Stainless Steel grade 304
Heat Resistance
- Can be exposed continuously without appreciable scaling to a max of 1600°F(871°C).
- Maximum exposure temperature is about 1450°F (788°C), for intermittent exposure
- Has an oxidation weight gain of 10mg/cm 2 in 1,000 hours, in temperatures over 1600°F (871°C).
Heat Treatment
- Solution Treatment (Annealing) – Heat to 1010-1120°C and cool rapidly.
- Use low side of range for intermediate annealing.
- This grade cannot be hardened by thermal treatment.
Cold Working
- hardens at high rate, creating a very high strength from cold rolling and from roll forming.
- more difficult to work than other austenitic stainless steels, due to its high work hardening rate.
- strain-hardened austenitite steel undergoes partial transformation into martensitite steel during this process.
- severe cold deformation can still occur, due to residual ductility.
- Grade 301 becomes strongly magnetic when cold rolled
Welding
- must be annealed for maximum corrosion resistance
- material will lose temper in the heat affected weld zone.
- Welding and post weld annealing will both remove high strength induced by prior cold rolling.
- Spot welding is commonly used to assemble cold rolled 301 components
| Grade & Brand | |
| Commodity | SUS301 Stainless steel coil |
| Grade | SUS301 |
| Brand | TISCO, BAO STEEL, POSCO |
| Certification | MTC,ISO, SGS, BV, etc |
| Dimension & Standard | |
| Thickness | 0.3mm-60mm |
| Width | 1000mm, 1219mm(4feet), 1250mm, 1500mm, 1524mm(5feet), 1800mm, 2200mm or as your requirements |
| Length | 2000mm, 2440mm(8feet), 2500mm, 3000mm, 3048mm(10feet), 5800mm, 6000mm or as your requirements |
| Surface | NO. 1, 2D, 2B, BA, NO. 3, NO. 4, NO. 240, NO. 400, Hairline(HL), 8K(mirror), Brushed |
| Standard | SUS, JIS |
| Delivery & Payment | |
| Delivery time | 3-7 Working days after confirmed the order |
| MOQ | 1 ton |
| Package | Steel/wooden pallet,with edge protector, steel hoop and seals, or as per customers' requirements. The inner size of container is below: 20FT GP: 5.8m(length) X 2.13m(width) X 2.18m(high) about 23MTS 4 0FT GP: 11.8m(length) X 2.13m(width) X 2.18m(high) about 27MTS 40FT HG: 11.8m(length) X 2.13m(width) X 2.72m(high) about 27MTS |
| Payment term | We accept 10%-30%T/T in advance,the balance before the shipment or 100% irrevocable LC at sight or Western Union. |
| Advantages | Showing the splendor quality, wear-resistant as well, strong corrosion resistance and decorative effect, durable and beautiful in good taste. |
