Wide 9.5- 420mm Stainless Steel 316 Strips Application Heat Exchanger BA 2B Finish
1. Products Details
| Commodity | 316l Stainless Steel Strip |
| Grade | 301,302,304,304L,316,316L,310S,309S,321,301,310 |
| Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification | SGS,BV,IQI,TUV,ISO,etc |
| Thickness | 0.3mm-25mm |
| Width | 1000,1219,1250,1500mm, or as your requirements |
| Length | 2000,2438,2500,3000,6000mm, or as your requirements |
| Surface | No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film. |
| Standard | ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc |
| Delivery | 5-7 days after confirming the order |
| MOQ | 1 Ton |
2. Chemical Properties:
| C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316 (S31600) |
0.08 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
| 316L (S31603) |
0.03 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
Mechanical Properties:
| Grade | Tensile Strength ksi (min) |
Yield Strength 0.2% ksi (min) |
Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
| 316 (S31600) |
75 | 30 | 40 | 217 | 95 |
| 316L (S31603) |
70 | 25 | 40 | 217 | 95 |
316 standards
CHINA:06Cr17Ni12Mo2
ASTM/ASME: UNS S31600 316L
AFNOR: Z 6 CND 17-11
DIN: 1.4401
3. Feather and Applications
1, Features: by adding Mo, so its corrosion resistance, resistance to atmospheric corrosion resistance and high temperature strength particularly well, and can be used in critical conditions. Excellent work hardening (non-magnetic); High temperature strength outstanding; Solid solution state non-magnetic; Cold rolled product outward appearance luster, beautiful; Relative to 304 l stainless steel, the price is higher.
2. Use: water with equipment, chemical, dyestuff, papermaking, oxalic acid, fertilizer and other production equipment; Photography, food industry, coastal facilities, rope, CD rod, bolts and nuts
