EN 10025 S275JR PLATE Carbon Steel S275JR Sheet Plate Fe430B Hot Rolled Structural Steel Plate
Price:
0.85 USD/KG
MOQ:
100KGS
Delivery Time:
7 Working Days
Brand:
Mittel
Product Description
EN 10025 S275JR PLATE Carbon Steel S275JR Sheet Plate Fe430B Hot Rolled Structural Steel Plate
STANDARD SPECIFICATION FOR CARBON STEEL S275JR SHEET PLATE
Standard : DIN 17100, DIN 17102, ASTM, GB/T700, JIS G3106, EN 10025, EN 10025-2: 2004 Hot rolled products of structural steels. Technical delivery conditions for non-alloy structural steels
Width : 1000-4000mm
Thickness : 3-620mm
Length : 3000-18500mm
Surface Finish : PE coated, anti rust oiled, checkered, Galvanized, anti rust varnished, Black painted, color coated etc
Application : Pressure Vessel Plate, Steel Boiler plate
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank, Circle, Ring etc.
S275JR CARBON STEEL SHEET PLATE EQUIVALENT GRADES
| EU EN | DIN,WNr | JIS | AFNOR | BS | Steel No. | GOST | ISO | IS |
| S275JR | RSt42-2 St 44-2 |
SS400 | E28-2 | 161-430 43A 43B |
1.0044 | St4ps St4sp |
E275B | IS2062 |
CHEMICAL COMPOSITION OF EN 10025-2 S275 SHEET PLATE
| C | Mn | P | S | N | Cu | CEV |
| max 0.22 | max 1.5 | max 0.04 | max 0.04 | max 0.012 | max 0.55 | max 0.42 |
MECHANICAL PROPERTIES OF S275JR SHEET PLATE
| Min. yield strength Reh MPa |
Tensile strength Rm MPa |
Minimum elongation - A Lo = 5,65 * √So (%) |
Notch impact test | |||||||||||
| Steel grade | Nominal thickness mm |
Nominal thickness mm |
Nominal thickness mm |
Temperature | Min. absorbed energy | |||||||||
| ≤16 | >16 ≤40 |
>40 ≤63 |
>63 ≤80 |
>80 ≤100 |
>100 ≤125 |
>3 ≤100 |
>100 ≤125 |
>3 ≤40 |
>40 ≤63 |
>63 ≤100 |
>100 ≤125 |
°C | J | |
| S275JR | 275 | 265 | 255 | 245 | 235 | 225 | 410-560 | 400-540 | 23 | 22 | 21 | 19 | +20 | |
