41Cr4 Scr440 5140 Alloy Steel Plate 10 - 140mm Cutting
41Cr4 Alloy Steel Plate Scr440 5140 Steel Plate 10 - 140mm Steel Plate Cutting
41Cr4 steel is a Chrome Manganese steel used in the manufacture of quenched and tempered bars where strength required is less than SAE 4140 steel bars.
It is also suitable for induction hardening with a minimum hardness of 52HRC.
The cold-upsettable steel 41Cr4 can be cold-formed with suitable tools with a low to medium rate of forming according to the usual forming methods on single-stage and multi-stage presses. It is used for normed screws and screws manufactured according to drawings of strength class 8.8 in the thick dimension range. Also used for high-strength parts manufactured according to drawings (eg. ball studs).
Competitive Advantage for 41Cr4 material steel plate :
- Available in stock for immediate shipment
- High strength,
- High tenacity
- Good hardenability
- High resistance to thermal properties.
- Competitive price
1. Supply Range of 41Cr4 steel
- Round Bar: diameter 20mm – 300mm
- Steel Plate and Steel Block: thickness 10-140mm x width 100-2200mm
- 10-120mm thickness 41Cr4 plate are available all the time in stock,
- 90-150mm thickness plate to be newly production in 8-10 days lead time.
Surface Finish: Black Surface, Milled Surface or Polished Surface as per given requirements
.
2. Relevant AISI 5140 Specification and Equivalent Steel Grades
| Country | USA | German | Japan |
| Standard | ASTM/AISI A29 | EN 10083-3 | JIS G4053 |
| Grades | 5140 | 41Cr4 | SCr440 |
3. ASTM 5140 Material Chemical Composition and Equivalent
| Standard | Grade/Steel Number | C | Mn | P | S | Si | Cr | Ni |
| ASTM A29 | 5140 | 0.38-0.43 | 0.70-0.90 | ≤0.035 | ≤0.040 | 0.15-0.35 | 0.70-0.90 | – |
| EN 10083-3 | 41Cr4 / 1.7035 | 0.38-0.45 | 0.60-0.90 | ≤0.025 | ≤0.035 | ≤0.40 | 0.90-1.20 | – |
| JIS G4053 | SCr440 | 0.38-0.43 | 0.60-0.90 | ≤0.030 | ≤0.030 | 0.15-0.35 | 0.90-1.20 | ≤0.25 |
