3mm Astm A240 Aisi 304 Square Stainless Steel Plates
ASTM 304 Stainless Steel Sheet and Plate , NO.1 Surface. 304 Stainless Steel Plate En 10204 certificate 3.1
Quick Detail
304 stainless steel plate
|
Description
Mile Edge BAOSTEEL 304 Stainless Steel Plate, NO.1 NO.4 Surface 304 SS plate
About our 304 stainless steel plate
| Material | 304 |
| Size | width:1500-1800 mm length: 3000-6000mm thickness: 3.0 -120mm |
| Surface | original surface is NO.1, we can make surface treatment like: 2B BA NO.4 mirror and pvc coat |
| Brand | TISCO JISCO BAOSTEEL POSCO.etc |
| packing |
standard export seaworthy packing or as customer required. |
Main material of our products: grade 201 301 304 304L 309S 310S 310H 316L 317L 321 409L 420 430 436 904L duplex stainless steel .etc
Main producs: stainless steel sheet/plate coil, stainless steel pipe, stainless steel bars.etc
Surface and Applications
|
Surface finish |
Characteristics and application |
|
No.2B |
The surface brightness and flatness of no2B is better than no2D. then through a special surface treatment to improve its mechanical properties,No2B could nearly satisfy comprehensive uses. |
|
No.3 |
Polished with abrasive belt of git#100-#200, have better brightness with discontinuous coarse stria, used as inner and external ornaments for building, electrical appliances and kitchen utensils etc. |
|
No.4 |
Polished with abrasive belt of grit #150-#180,have better brightness with discontinuous coarse stria, but thinner than No3, are used as bathtub buildings inner and external ornaments electrical appliances kitchen utensils and food processing equipment etc. |
|
HL |
Polished with abrasive belt of grit #150-#320 on the NO.4 finish and has continuous streaks, mainly used as buildings ornaments elevators, door of building, frontal plate etc. |
|
BA |
Cold rolled, bright annealed and skin-passed, the product have excellent brightness and good reflexivity like mirror, kitchen apparatus, ornament etc. |
|
8K |
The product have excellent brightness and prefer reflexivity can to be the mirror |
Specifications
Mile Edge BAOSTEEL 409L Stainless Steel Plate, NO.1 NO.4 Surface 409L SS plate
size: 3.0 - 100mm x 1500mm x 6000mm or as required
Chemical Compostion of 304
|
C |
Si |
Mn |
P |
S |
Cr |
Ni |
|
|
<=0.08 |
1.00 |
2.00 |
0.04 |
0.03 |
18-20 |
8-10 |
|
|
Mechanical properties |
|||||||
|
|
Heat Treatment |
Yield strength(N/mm2) |
Tensile strength |
Elongation (%) |
Hardness |
||
|
HB |
HRB |
HV |
|||||
|
|
304 |
≥205 |
≥520 |
≥25 |
≤187 |
≤80 |
≤175 |
National grade of 304 : ASTM 304 / S30408 / EN 1.4301
Density(g/cm3) : 7.93
Advantage of us:
|
1, high quality and competitive price 2, have 15000 ton stainless steel products stock 3, fast deliver 4, more than 12 years export experience 5,Near Shanghai Port, the traffice is very good. 6,special in stainless steel products |
