St12 ST13 DDQ Material Cold Rolled Steel Sheet 1.2*1500*3000mm Carbon Steel Sheet
Cold Rolled Mild Steel Sheet SPCC DC01 DC04 ST12 Carbon Steel Sheet DDQ Material Steel Strip
1 Thickness: 0.2-5.0mm
2 Width: 100-1010/1220/1250mm
3 Length as per customer's request.
4 Steel Grade:SPCC, SPCD, SPCE, DC01, DC02, DC03, SAE 1006.
Soft commercial quality, Full hard quality or Deep Drawing quality.
5 Packing: standard export packing.
| Brand Name | MITTEL |
| Product Name | Cold Rolled Steel Sheet |
| Capacity | 10000 mts/month |
| Standard | DC01,DC02,SAE1006 SPCC |
| Thickness | 0.2-5.0mm |
| Width | 100-1010/1220/1250mm |
| Tolerance | Width:+/- 2mm ,Thickness:+/-0.02 |
| Lenght | As customer's request |
| Payment | L/C at sight or usance, T/T, DDP / |
| Packing | Mill's standard export sea-worthy packing |
DIN EN 10130 DC01 Steel (1.0330 Material) Data Sheet
DC01 steel (1.0330 material) is a European standard cold-rolled quality low-carbon steel flat product for cold forming. In BS and DIN EN 10130 standard, it contains 5 other steel grades: DC03 (1.0347), DC04 (1.0338), DC05 (1.0312), DC06 ( 1.0873) and DC07 (1.0898), the surface quality is divided into 2 types: DC01-A and DC01-B. In addition, this steel is also used under electrogalvanizing conditions. The designation of the steel is DC01+ZE (or 1.0330+ZE), and the standard is EN 10152.
DC01 Meaning and Definition
- D: (Drawing) flat products for cold forming
- C: Cold rolled
- DC01: Drawing quality
- DC03: Deep drawing quality;
- DC04, DC05: Special deepdrawing quality;
- DC06: Extra deepdrawing quality;
- DC07: Super deep drawing quality.
Examples of Steel Names
- DC01-A: Allow defects that do not affect formability or surface coating, such as pores, slight dents, small marks, slight scratches, and slight coloring.
- DC01-B: Better surfaces shall be free from defects that may affect the uniform appearance of high-quality paints or electrolytic coatings. The other surface should meet at least surface quality A.
- DC01+ZE: Electrolytically zinc coated
- DC01EK: Conventionally enamelled
DC01 Steel Data Sheet
The tables and lists below give grade DC01 steel data sheet and specification including chemical composition, mechanical properties, welding, etc.
Chemical Composition
DC01 steel chemical composition is listed in the following table based on ladle analysis.
| Country (Region) | Standard | Chemical Composition (ladle analysis), %, ≤ | Surface quality | Deoxidation | Classification | ||||
| Steel name (Steel number) | C | Mn | P | S | |||||
| European Union | EN 10130 | DC01 (1.0330) | 0.12 | 0,60 | 0,045 | 0,045 | A, B | Manufacturer’s discretion | Non-alloy quality steel |
| EN 10152 | DC01+ZE (1.0330+ZE) | A, B | |||||||
| EN 10139 | DC01-C390, C340, C440, C490, C590, C690 | – | |||||||
Notes:
- EN 10130 – Cold rolled low carbon steel flat products;
- EN 10152 – Electrolytically zinc coated cold rolled steel flat products.
- EN 10139 – Cold rolled uncoated low carbon steel narrow strip.
DC01+ZE Steel Mechanical Properties
The table below lists DC01+ZE steel mechanical properties.
| Mechanical properties, Part-1 | |||||||
| Country (Region) | Standard | Steel name (Steel number) | Yield strength (MPa), 0.2 % offset | Tensile strength (MPa) | Elongation, ≥ % | Surface quality | Absence of stretcher strain marks |
| European Union | EN 10130 | DC01 (1.0330) | 140 (assumed) -280 | 270-410 | 28 | A, B | – |
| EN 10152 | DC01+ZE (1.0330+ZE) | 3 months | |||||
Notes:
- Yield strength: When the thickness is ≤0.7 mm but >0.5 mm, the yield strength value should be increased by 20 MPa. For thicknesses ≤0.5 mm, the value should be increased by 40 MPa.
- Elongation: When the thickness is ≤0.7 mm but >0.5 mm, the minimum value of elongation should be reduced by 2 units. For thicknesses ≤0.5 mm, the minimum value shall be reduced by 4 units.
A: We are both. We have our own factory and also work as traders, giving you the best prices and flexible service.
A: We offer custom sizes, supply from our factory or top mills (like Baosteel/Shagang), ensure quality with ISO certification, and provide stable supply.
A: We supply carbon steel, stainless steel, alloy steel, and construction materials like pipes, coils, sheets, beams, and bars.
A: Yes. We customize dimensions (length, width, thickness), slit coils, and meet different standards and packaging needs.
A: Send us product name, specifications, quantity, and destination port. We reply quickly.
A: We accept T/T (30% deposit, 70% before shipment) or L/C at sight.
A: Standard items: 7-10 days. Custom orders: 15-25 days.
A: We ship from Shanghai or Tianjin with major shipping companies. We handle all export procedures under FOB, CIF, or CFR terms.
