En 10130 Standard Galvanized Steel Coils Oil Fb Surface Annealing Dc01 Dc04 Rolled
COLD ROLLED STEEL COILS(CRC)
Width (mill edge): 914-1500mm
Max. Thickness: 0.3--2.0mm
Min. Thickness: 0.3mm
Inside diameter: 508mm or 610mm
Outside diameter: 850~1500mm
Description of goods: we can supply soft, semi-soft, cold hard and stainless worked cold-rolled steel coils at customer's option
Steel Grade: SPCC-SD, SPCC-1B, DC01, DC02, DC03, DC04
| Name | Cold rolled steel coil/sheet |
| Standard | JIS 3302 / ASTM A653 / EN10143 |
| Grade | Q235, SGCC, CGCC, SPCC, DX51D, DX52D, SPHC, DC01, DC03, DC04, ST12 |
| Width | 750~1250mm |
| Thickness | 0.12~3.0mm |
| Surface treatment | chromated / galvanized/oiled/annealed |
| ID coil | 508mm or 610mm |
| Coil weight | 3-8 MT |
| Package: | Standard exporting package |
| Application | Industrial panels, roofing and siding for painting |
| Price terms | FOB,CFR,CIF |
| Payment terms | 30%TT in advance+70% TT or irrevocable 100%L/C at sight |
| delivery time | within 25 days |
Specification
| Standard | AISI, ASTM, BS, DIN, GB, JIS |
| Grade | DC01 , DC03 , DC04 , DC05 |
| Thickness | 0.2 - 3.0 mm |
| Width | Below 1220 mm (according to your need) |
| Coil Weight | 3-11tons , or according to Buyer's requirement |
| Coil ID | 508 / 610 |
| Technique | Cold Rolled |
| Surface | Bright , Matt |
| Shipment time | within 25-30 workdays |
| Export package | waterproof paper, galvanized steel covered and fixed with steel strip ,or as customer's request. |
| Payment | T/T, L/C at sight |
Grade & Application
1. DC01 ( SPCC , ST12 )--- Ordinary use
Forming of casing of home appliances including refrigerator, oil tank, and steel furniture, etc.
2. DC03(SPCD,ST13)--- Stamping grade
Steel for punching forming of automobiles, home appliances, buildings, etc.
3. DC04(SPCE,ST14)--- Deep punching grade
Steel for deep drawing forming of head lighting, oil tank, car door and window, etc.
4. DC05(SPCF,ST15)--- SDDQ
Complicated base plate and oil sump
5. DC06 (SPCG,ST16)---EDDQ
Car door inner panel, complicated base plate,oil sump, wheel casing, front and rear fenders, etc.
