6000mm TISCO Laser Cutting Stainless Steel Sheet 316LN Cold Rolled Stainless Steel Plate
ASTM SA240 316LN Stainless Steel Plate / Laser Cutting Stainless Steel Plate SS Plate 316LN Alloy
Detail information of the stainless steel plate:
|
Commodity |
316LN Stainless Steel Plate |
|
Grade |
201,202,304,304L,316,316L,316LN,316Ti, 310S,309S,321,301,310,410,420,430,904L |
|
Brand |
TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
|
Certification |
SGS, BV, IQI, TUV, ISO, etc |
|
Thickness |
0.4mm-40mm |
|
Width |
1000,1219,1250,1500mm, or as your requirements |
|
Length |
2000,2438,2500,3000,6000mm, or as your requirements |
|
Surface |
No.1, 2B, BA, 8K Mirror, Hairline, Satin, Embossed, Brush, No.4, HL, Matt, PVC film, Laser film |
|
Standard |
ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME, etc |
|
Delivery time |
5-7 days after confirming the order |
|
MOQ |
1 Ton |
|
Advantages |
Showing the splendor of your quality, wearresistant as well. |
About 316LN Stainless Steel
Stainless steel grade 316LN is an austenitic type of steel that is a low carbon, nitrogen-enhanced version of grade 316 steel. The nitrogen content in this steel provides solid solution hardening, and raises its minimum specified yield strength. It also possesses good resistance to general corrosion and pitting/crevice corrosion.
Technical Data Mechanical Properties
| Temper | Annealed | Cold worked | ||
|---|---|---|---|---|
| Tensile Rm | 75 | ksi (min) | 125 | ksi (min) |
| Tensile Rm | 515 | MPa (min) | 860 | MPa (min) |
| R.p. 0.2% Yield | 30 | ksi (min) | 100 | ksi (min) |
| R.p. 0.2% Yield | 205 | MPa (min) | 690 | MPa (min) |
| Elongation (2" or 4D gl) | 35 | % (min) | 15 | % (min) |
Physical Properties (Room Temperature)
| Specific Heat (0-100°C) | 485 | J.kg-1.°K-1 |
| Thermal Conductivity | 16.3 | W.m -1.°K-1 |
| Thermal Expansion | 16.5 | mm/m/°C |
| Modulus Elasticity | 200 | GPa |
| Electrical Resistivity | 7.4 | μohm/cm |
| Density | 7.99 | g/cm3 |
Chemical Composition (% by weight)
| Element | Min | Max |
|---|---|---|
| C | - | 0.03 |
| Mn | - | 2 |
| Ni | 13 | 15 |
| Cr | 17 | 19 |
| Mo | 2 | 3 |
| S | - | 0.1 |
| Si | - | 0.75 |
| P | - | 0.25 |
Applications
Grade 316LN stainless steel is widely used in the following applications:
- Trauma nails
- Orthopedic implants
- Neurological applications
- Surgical instruments
