S350GD Z275 Galvanized Steel Coil Slit Cutting 3.0mm Thickness
EN 10346 S350GD +Z275 Galvanized Steel Coil / High Strength Galvanized Steel Coil 0.3 - 3.0mm Thickness
| Commodity | S350GD Galvanized Steel Coils |
| Standard | JISG3302 /EN10346/ASTMA653 |
| Thickness | 0.4-3.0mm |
| Width | 600-1250mm |
| Zinc Coating | Z30-275g/M2 |
| Coil ID | 508/ 610mm |
| Coil Weight | Within 8MT |
| Min Order | 5 Tons Per Size |
| Spangle | Regular , Zero Spangle |
| Surface | Chromated,Skin-Passed,Non Skinpassed |
| Payment Terms | T/T Or L/C |
| Delivery Terms | FOB/CFR/CIF |
| Delivery Time | 5 - 12 Days After Received The Deposit Or As Client Requirement |
| Packing | Standard Seaworthy Export Packing |
About S350GD Galvanized Steel Coil
S350gd is a grade in the European standard “EN 10346-2009 Continuous Hot-Dip Galvanized Steel Sheet Products”, which is a galvanized steel sheet. S350G is structural steel requiring tensile strength greater than 350MPa, D means galvanized sheet, so s350gd is structural galvanized sheet with yield strength greater than 350MPa
The S350G is available in the following hot dip coatings: S350GD+Z (galvanized), S350GD+ZF (galvanized-iron), S350GD+ZA (galvanized-aluminum), S350GD+AZ (aluminum-zinc), S350GD+AS (galvanized-iron) aluminum silicon).
Features of S350GD Galvanized Steel Coil
S350GD galvanized sheet (coil) has the characteristics of strong coating adhesion, strong erosion resistance, precise control of galvanized layer thickness, high dimensional accuracy, flat profile, good mechanical properties, processing performance and welding performance. They can be used to manufacture interior and exterior panels, structural parts and reinforcements for automobiles.
Percent Chemical Composition Of Steel S350GD: EN 10346-2009
| C | Si | Mn | P | S |
| max 0.2 | max 0.6 | max 1.7 | max 0.1 | max 0.045 |
Mechanical Properties Of Steel S350GD (1.0529)
| Rm - Tensile strength (MPa) | 420 |
| Rp0.2 0.2% proof strength (MPa) | 350 |
| A - Min. elongation Lo = 80 mm (%) | 16 |
Equivalent Grade For Steel S350GD (1.0529)
| EU | European old |
| EN | EN |
| S350GD | FeE350G |
Application Industry
Prefabricated steel buildings, industrial and commercial roofing and cladding, agricultural buildings, building accessories, light steel frames, building pipes
